Model 406
(with reverse drive)
NOTE: Use 12 ounces of
Plastilube #0 grease. Order
Part No. 737-0133.
TILLER CHAIN CASE 784-0106 (TINES)
PARTS LIST FOR MODEL 406 TILLER
REF.
NO.
PART
NO.
CODE
DESCRIPTION
REF.
NO.
PART
NO.
CODE
DESCRIPTION
1
736-0176
FI-Wash.
1
/
4
" I.D.
X
.93" O.D.
20
750-0570
Step Spacer
2
736-0329
L-Wash.
1
/
4
" I.D.*
21
736-0169
L-Wash. 3/8" I.D.*
3
710-0513
Hex Bolt 1/4-28
X
.62" L(|.
22
712-0711
Hex Nut 3/8-24 Thd.‘
w/Patch
23
713-0327
#35 Chain 3/8" Pitch x 52
4
716-0131
External Snap Ring—5/i " Dia.
Links Endless
5
784-0139
Input Shaft Ass’y-
24
05034
Bearing Housing 1.38" I.D.
6
741-0304
Bearing 5/8" I.D. x
W O.D.
25
750-0471
Spacer
X
1.860" Lg.
26
741-0155
Ball Bearing .625" I.D. x
7
750-0275
Sprocket Hub Tubing 3/3"
1.38" O.D.
X
.437
I.D.
X
5/8" O.D.
X
1 . 9 )
2 7
710-0599
Hex Wash. SF-Tap Scr.
8
710-0629
Hex Bolt 3/8-24
X
2.75" Lg.*
1
/
4-20
X
.50" Lg.
9
736-0258
FI-Wash. 3/8" I.D. x 1.2ii"
28
736-0329
L-Wash.
1
/
4
" I.D.*
10
713-0331
Sprocket Ass’y-
29
710-0118
Hex Bolt 5/16-18
X
.75" Lg.*
11
713-0328
#50 Chain 5/8" Pitch x -16
30
712-0267
Hex Nut 5/16-18 Thd.*
Links Endless
31
736-0119
L-Wash. 5/16" I.D.*
12
14986
Tine Shaft Ass’y.
32
710-0599
Hex Wash. SF-Tap Scr.
13
731-0487
Dust Cup
1
/
4-20
X
.50" Lg.
14
721-0175
Seal Ring Single Lip
33
710-0653
Hex Wash. Hd. Tap Scr.
15
14984
Ass’y. Tiller Housing—R.H.
1
/
4-20
X
.38" Lg.
16
721-0170
Gasket
34
736-0270
Bell-Wash. .265" I.D. x .75"
17
14985
Ass’y. Tiller Housing—L H.
—
737-0133
Grease—Plastilube #0 (12 oz.)
18
731-0374
Flange Brg. 1.00" I.D.
19
736-0163
FI-Thrust Wash. 1.0" I.C . x
.03 Thk.
20
