Model 406
PARTS LIST FOR MODEL 406 TILLER
REF.
NO.
PART
NO.
CODE DESCRIPTION
REF.
NO.
PART
NO.
CODE DESCRIPTION
1 710-0299 Hex Bolt 1/4-28 X 1.0" Lg.* 50 14975 638 Frame Rail—L.H.
2 720-0180 Grip 51 726-0175 Clamp 5/16" Dia.
3 747-0517 Clutch Lever 55 720-0165 Ball Knob
1 1
/
4
" Dia.
4 712-0117 Hex Cent. L-Nut V4-28 Thd. 56 736-0169 L-Wash. 3/8" I.D.*
5 710-0458 Carr. Bolt 5/16-18 x 1.75"* 57 712-0798 Hex Nut 3/8-16 Thd.*
7 784-0031 Clutch Grip Ass’y-—L.H. 59 15393 Brkt. Reinforcement
9 15093C N Clutch Cable Bracket 61 784-0026 Tine Shield Ass’y.
10 710-0607 Hex Wash. S-Tap Scr. 62 714-0149B N Hairpin Cotter
5/16-18 X .62" Lg. 63 711-0415 Clevis Pin 3/8" Dia.
11 712-0256 Hex Nut 5/16-24 Thd. 64 749-0642 Handle—R.H.
12 736-0119 L-Wash. 5/16" I.D.* 65 720-0195 Hand Knob
13 746-0535 Clutch Control Cable (Tines) 66 714-0127 Cotter Pin 1/16" Dia. x .75"*
14 712-0267 Hex Nut 5/16-18 Thd.* 67 712-0375 Hex Cent. L-Nut 3/8-16 Thd.
15 710-0118 Hex Bolt 5/16-18 X .75" Lg.* 68 720-0143 Grip
16 784-0271 Handle Panel Ass’y- 69 738-0575 Shoulder Bolt .375" Dia. x
17 749-0643 Handle—L.H. 1.37" Lg.
18 712-0798 Hex Nut 3/8-16 Thd.* 70 741-0402 Hex Flange Plastic Bearing
19 736-0169 L-Wash. 3/8" I.D.* 71 738-0561 Shoulder Nut V 4-20 Thd.
20 736-0105 Bell-Wash. 3/8" I.D. 72 746-0502 Throttle Control Wire M y ^
21 710-0253 Hex Bolt 3/8-16 X 1" Lg.* 73 831-0823A N Throttle Control Box Ass’y.
22 714-0507 Cotter Pin 3/32" Dia. x 3/4" * 74 736-0219 Bell-Wash. .40" I.D. x 1.13"
23 725-0157 Cable Tie 75 784-0022 Handle Pivot Bracket
24 747-0432 Tiller Flap Rod 76 738-0281 Shoulder Bolt 5/8" Dia. x
25 14989 End Cover Ass’y.—L.H. .165" Lg.
14990 End Cover Ass’y.—R.H. 77 784-0019 Handle Mtg. Bracket
(Not Shown) 78 784-0025 Adj. Handle Ass’y.
26 736-0242 Bell-Wash. 5/16" I.D. 79 712-0375 Hex Cent. L-Nut 3/8-16 Thd.
27 712-0267 Hex Nut 5/16-18 Thd.* 80 736-0105 Bell-Wash. .40" I.D. x . 88 "
28 15390 638 Side Shield 81 736-0253 Bell-Wash. V 2 " I.D. x 1.00"
29 15397 L.H. Tine Ass’y. Comp. 82 711-0765 Lock Pin 5/16" Dia. x 8 "
15398 R.H. Tine Ass’y. Comp. 83 784-0023 Lower Sliding Ass’y.
30 712-0241 Hex Nut 3/8-24 Thd.* 84 736-0463 FI-Wash. .291" I.D. x .62"
31 736-0169 L-Wash. 3/8" I.D.* 85 732-0145 Compression Spring 1" Lg.
32 710-0191 Hex Bolt 3/8-24 x 1.25" Lg.* 86 738-0147 Shoulder Bolt Vz" Dia. x
33 714-0149B N Hairpin Cotter .170" Lg.
34 14978 Tine Adapter Ass’y. 87 710-0599 Hex Wash. S-Tap Scr. V 4-20
35 742-0106 Tine 12" R.H. X .50" Lg.
36 742-0105 Tine 12" L.H. 88 736-0242 Bell-Wash. 5/16" I.D.
37 711-0415 Clevis Pin 3/8" Dia. 89 712-0158 Hex Cent. L-Nut 5/16-18 Thd.
38 710-0779A Truss Mach. AB-Tap Scr. #10 x 90 736-0159 FI-Wash. .344" I.D. x .87"
.5" Lg. 91 735-0126 Rubber Wash. .33 I.D. x .87"
40 14979 Tine Shield Flap 92 746-0496 Control Cable (Forward)
41 710-0736 Hex Bolt 5/16-18 X 1.0" Lg.* 93 746-0572 Control Cable (Reverse)
42 738-0507B N Shid. Bolt 1 / 2 " Dia. x .43" 94 736-0285 FI-Wash. .62" I.D. x 1.57"
43 736-0117 FI-Wash. 3/8" I.D. x 5/8" O.D. 95 784-0270 Clutch Grip Ass’y.—R.H.
44 710-0216 Hex Bolt 3/8-16 X 3/4" Lg.* 96 710-0528 Hex Bolt 5/16-18 X 1.25"*
45 14992 Depth Bar Ass’y.
'C-L
*For faster service obtain standard nuts, bolts and washers locally.
If these items cannot be obtained locally, order by part number and
size as shown on parts list.
CODE; N notates a new part (not previously existing). A three digit
number is the color code (use if color or finish is important when
ordering parts). See chart below, [i.e., (part no.)-638 for Red Finish].
Color Codes
NOTE
Specifications subject to change without notice or
obligation.
460—Green Flake 630—Blue
483—Charcoal Grey 635—Grey
498—Yellow 636—White
499—Beige 637—Black
606—Orange 638—Red
629—Silver Flake 640—Green
