MTD 219-406-000 - Manual (Page 19)

Model 406
(with reverse drive)
PARTS LIST FOR MODEL 406 TILLER
REF.
NO.
PART
NO.
CODE DESCRIPTION
REF.
NO.
PART
NO.
CODE DESCRIPTION
1 750-0219 Spacer .375" I.D. x .5" 40 736-0119 L-Wash. 5/16" I.D.*
O.D. X 2" Lg. 41 710-0117 Hex Bolt 5/16-24 x 1.00" Lg.*
2 746-0535 Clutch Control Cable
(\\r\es)^3"
42 754-0195A N “V”-Belt
3 15093 Clutch Cable Bracket 43 736-0176 FI-Wash.
V a "
I.D. X .93" O.D.
4 710-0118 Hex Bolt 5/16-18 X .75" Lg.* 44 736-0329 L-Wash. 1 / 4 " I.D.*
5 732-0387 Extension Spring .50" O.D. 45 710-0412 Hex Bolt 1/4-28 X .75" Lg.
X 2.5" Lg. 46 736-0921 L-Wash. 1 / 2 " I.D.*
6 712-0266 Hex Cent. L-Nut 3/8-16 Thd. 47 712-0206 Hex Nut 1/2-13 Thd.*
7 712-0287 Hex Nut 1 / 4-20 Thd.* 48 750-0579 Spacer .38" I.D. x .62" O.D. x
8 732-0445 Extension Spring .50" O.D. 2.18" Lg.
X 1.55" Lg. 49 736-0169 L-Wash. 3/8" I.D.*
9 15093C N Clutch Cable Bracket 50 756-0389A N Fl-Pulley w/Flanges 6 " O.D.
10 710-0189 Hex Bolt 5/16-18 X 3" Lg.* 51 756-0405 Fl-ldler w/Flanges 3.75" O.D.
11 746-0496 Clutch Control Cable 42" Lg. 52 756-0464 Double Fl-Pulley 5/8" I.D.
57/ (Forward)
fC
2
‘
53 756-0313 Fl-ldler w/Flanges 2.12" O.D.
12 746-oe?e Clutch Control Cable Lg. 54 738-0147 ShId. Bolt .500" Dia. x .170" Lg.
(Reverse) 55 784-0140 Flange Extension
13 14973 Engine Mounting Plate 56 712-0267 Hex Nut 5/16-18 Thd.*
14 710-0830 Hex Bolt 3/8-24 x 3" Lg. 57 784-0129 Idler Brkt. Ass’y.—Tines
15
—
Springs (Part of Ref. No. 11 58 738-0183 Shid. Bolt. .500" Dia. x
and 12 ) .215" Lg.
16 712-0107 Hex Cent. L-Nut У 4-20 Thd. 59 714-0388 #61 Hi-Pro-Key 3/16" X 5/8" Dia.
17 732-0486 Extension Spring .41" O.D. 60 750-0551 Spacer .647" I.D. x 2.75" Lg.
X 2.05" Lg. 61 712-0241 Hex Nut 3/8-24 Thd.*
18 710-0442 Hex Bolt 5/16-18 X 1.5" Lg.* 63 14974 Frame Rail—R.H.
19 — Engine 64 736-0185 FI-Wash. .406" I.D. X .75"
20 714-0105 Sq. Key 3/16 X 1.00" Lg. 65 14991 Side Plate Ass’y.
21 784-0106 Chain Case Comp.—Tines 66 710-0938 Set Scr. 1/4-28 X .25" Lg.
22 784-0104A N Chain Case Comp.—Wheels 67 734-1378 R.H. Wheel Ass’y. Comp. 1 3 x 5
2 3 14975 Frame Rail—L.H. 734-1377 L.H. Wheel Ass’y. Comp. 1 3 x 5
2 4 723-0340 Counterweight 35# (Not Shown)
25 747-0507 Belt Keeper 734-1154 Tire Only
26 736-0270 Bell-Wash. .265" I.D. x .75" O.D. 734-1376 Rim Only
27 784-0131 Idler Brkt. Ass’y- 734-0255 Air Valve
(Wheel Reverse) 68 710-0237 Hex Bolt 5/16-24 X .62" Lg.*
28 738-0147 Shid. Bolt .500" Dia. x .170 69 710-0600 Hex Self-Tap Scr. 5/16-24 x
29 14969 Idler Brkt. Ass’y. .5" Lg.
(Wheel Forward) 70 736-0242 Bell-Wash. 5/16" I.D.
30 736-0326 FI-Wash. .51" I.D. x 1.0" 71 15399 Belt Keeper Brkt.
31 714-0131 #5 Hi-Pro-Key 1/8" x 5/8" Dia. 72 736-0315 FI-Wash. .75" I.D. x 1.5"
32 756-0386A N 1/2" V-Pulley 2.25" O.D. X 73 750-0470 Spacer .326" I.D. x .47" O.D. x
.503" I.D. .96" Lg.
33 754-0109 “V”-Belt 74 736-0256 FI-Wash. .635" I.D. X 1" O.D.
34 756-0166 “V”-Belt Idler 2.62" O.D. 75 714-0122 Sq. Key 3/16 x .75" Lg.
35 712-0116 Hex Ins. L-Nut 3/8-24 Thd. 76 14980A N Belt Cover
36 756-0465 1 / 2 " “V”-Pulley Ass’y. 77 710-0599 Hex Self-Tap Scr. 1 / 4-20 x .5" Lg.
37 754-0190 "V”-Belt 78 710-0653 Hex Wash. S-Tap Scr. V 4-20 x
38 710-0786 Hex Bolt 1/2-13 X 4" Lg.* .38" Lg.
39 736-0231 FI-Wash. .344" I.D. X 1.125"
•For faster service obtain standard nuts, bolts and washers locally.
If these Items cannot be obtained locally, order by part number and
size as shown on parts list.
19
