A p p e n d i x A : D i a g r a m s a n d P a r t s L i s t s
CHRISTIE DIGITAL SYSTEMS
A-7
August 7, 2003
# Description
Part
Number
1
Air Switch 1600 Assembly
195557-001
2 Igniter,
IGA-10
116715-001
Igniter,
IGA-15M
117124-001
3
Door Interlock Switch
578000-034
4 Capacitor
(SLC 20, 30) 530106-302
Capacitor
(SLC 40, 45, 70) 530122-009
5
Terminal Strip, with Wire Guard
586211-001
6
Control Assembly, 60 Hz (SLC 20, 30) 114173-002
Control Assembly, 50 Hz (SLC 20) 114173-011
Control Assembly, 50 Hz (SLC 30, 40, 45, 70) 114173-010
Control Assembly, 60 Hz (SLC 40, 45, 70) 114173-001
7
Power Input Terminal, 55 Amp
586210-601
8
Heat Sink Assembly (SLC 20, 30) 114109-002
Heat Sink Assembly (SLC 40, 45, 45R, 70) 195569-001
9
Leveling Foot (4)
520650-003
10
Fan Guard, 4.5 x 0.200/0.600 in DP
598931-496
11
Transformer, 208/230 VAC, 60 Hz (T1)(SLC20/30) 195773-001
Transformer,380/415
VAC50/60Hz(T1)(SLC20/30) 195773-004
Transformer, 208/230 VAC, 60 Hz (T1) (SLC 40) 195774-001
Transformer, 380/415 VAC,50/60Hz (T1) (SLC 40) 195774-004
Transformer,208/230 VAC,60 Hz (T1) (SLC 45/70) 195775-001
Transformer,380/415
VAC50/60Hz(T1)(SLC45/70) 195775-004
Transformer,208/230VAC,60Hz(T1)(SLC45R/70R) 195775-001
Transformer, 380/415 VAC, 50/60 Hz (T1)
(SLC45R/70R)
195775-004
12
PCB Assembly, Lamp Adjustment
195315-001
PCB Assembly, Lamp Adjustment
195315-002
13
Xenon Lamp Adjustment, Manual
195800-001
Xenon Lamp Adjustment, Motorized
195800-002
Xenon Lamp Adjustment, Auto-Focus, Motorized
195800-003
Xenon Lamp Adjustment, Auto-Focus, Manual
195800-004
Xenon Lamp Adjustment, Motorized, Manual
195800-005
14
Tap Switch Assembly, Lamp Current Adjustment
111972-002
15 Contactor,
Relay
(SLC 20, 30), 120V 571340-006
Contactor,
Relay
(SLC 40, 45, 70), 120V 571340-008
Contactor,
Relay
(SLC 20, 30), 230V 571340-007
Contactor,
Relay
(SLC 40, 45, 70), 230V 571340-009
16 Console
Tilt
Option
195535-001
Table A-3: Parts List for SLC Xenon Lamp Console (Rear View)
