Section 6 — Exploded Views and Parts Lists
^PARTS
LISTS
Series QP55-G Recreational Vehicle Generator
410VS - Drawing No. A7894-D
TEM
PART NO.
QTY.
DESCRIPTION
ITEM
PART NO.
QTY.
DESCRIPTION
1
21533
1
PISTON RING SET
30
72655
2
CRANKSHAFT 35 I.D. SEAL
3
71978
1
CONNECTING ROD WITH CAP
31
76361
1
THRUST WASHER
& BOLT
32
A5776
1
PRESSURE RELIEF BALL
4
71980
1
PISTON PIN
33
A7308
1
GOVERNOR SPOOL
5
71983
2
PISTON PIN RETAINER
34
78645
1
GOVERNOR RETAINER
6
21713B
1
CYLINDER HEAD GASKET
(C-RING)
7
A1442
8
FLANGED HEX HD,
35
78691
1
COVER, OIL PRESSURE
CAPSCREW M8-1.25 X 42
RELIEF
8
21742
4
M10 1.5 X 105MM HHFL
36
74908
1
M5-0.8 X 10MMTAPTITE
9
96699
1
PISTON
37
A8930
1
GOVERNOR GEAR ASSEMBLY
10
76701
1
CRANKCASE GASKET
38
A5771
1
OIL PRESSURE SPRING
11
45756
2
M6-1.0 X 10TAPTITE (THD.
39
B2104
1
SPRING WASHER
FORMING)
40
89280D
1
OIL SUMP ASSEMBLY
12
80308
2
BREATHER GASKET
42
78658
1
GOVERNOR ARM "R" PIN
13
80309
1
BREATHER COVER
43
78659
2
THRUST WASHER
14
80338
1
OIL BREATHER SEPARATOR
46
A7628
1
GOVERNOR ARM RC45
15
26925
1
PIPE PLUG-3/8"
48
C3396C
1
CRANKCASE SUB ASSEMBLY
16
83897
2
TAPPET, SOLID
49
84430
1
BALANCER
17
72694
2
PIVOT BALL STUD
50
86002
1
OUTER GEROTOR
18
72696
2
JAM NUT (ROCKER ARM)
51
86026
1
INNER GEROTOR
19
78672
1
SEAL, VALVE STEM
52
88396B
2
PUSH ROD
20
78694
1
PUSH ROD GUIDE PLATE
53
90416A
1
CRANKSHAFT ASSEMBLY
21
83907
2
ROCKER ARM
54
90747
1
BREATHER VALVE ASSEMBLY
22
21714
1
CYLINDER HEAD W/VALVE
55
C3150
1
ROCKER COVER GASKET
SEATS AND GUIDES
57
92362
1
ROCKER COVER W/FILL
23
86514
2
VALVE SPRING RETAINER
58
79246
4
M6-1.0 X 16MM HEX HEAD.
24
86515
4
VALVE SPRING KEEPER
SCREW. AND LOCKWASHER
25
86516
1
EXHAUST VALVE
59
83921
1
BEARING TUBE SHAFT
26
86517
1
INTAKE VALVE
60
77158
1
OIL SCREEN PICKUP ASSY.
27
89673
2
WASHER, VALVE SPRING
63
76329
1
OIL FILL PLUG
28
91308
2
VALVE SPRING
64
86254
1
"0" RING 17.8 I.D. X 2,4 THICK
29
A9877
1
CAMSHAFT ASSEMBLY
65
93064
1
OIL FILL CAP ASSEMBLY
