Section 6 — Exploded Views and Parts Lists
.PARTS
LISTS
Series QP55-G Recreational Vehicle Generator
Engine Sheet Metal - Drawing No. A7233-D
ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION
1 A4323 1 SCROLL, FLYWHEEL 27 31580 1 PIPE NIPPLE, 3/8" X 8.5" LG.
2 45756 8 SCREW, TAPTITE 28 38593 1 BRASS STREET ELBOW, 3/8"
M6-1.0 X 10MM 29 22473 1 FLAT WASHER, 1/4"-M6
3 29289 2.5 FT. FOAM TAPE 30 A6357 1 WRAPPER, ENGINE SPARK
4 SRV 91222-■D1 FLYWHEEL PLUG
5 67198-N 1 WASHER, BELLVILLE M20 31 A6360 1 WRAPPER, STARTER SIDE
6 67890 1 NUT, M20 X 1.5 32 A6489 1 WRAPPER, REAR GEAR
7 A4456 1 3/8" SPECIAL LOCK WASHER CASE
8 56893 21 SCREW, CRIMPTITE 33 A6359 1 WRAPPER, CARB. SIDE
#10-24 X .5" 34 10-74260 1 ASSEMBLY, WIRE-STARTER
9 A6358 1 COVER,TOP FLYWHEEL (#16)
10 91646 1 DEFLECTOR, EXHAUST 35 90892 1 SUPPORT, OIL FILTER
PORT 36 91159 1 BUSHING, RUBBER
11 92572 1 ASSEMBLY, IGNITION COIL 37 91160 1 WASHER, RUBBER
12 92079 2 SCREW, TAPTITE 38 91161 1 BOLT, SHOULDER-
M6-1.0 X 25MM M6-1.0 X 15MM
13 22717A 1 GROMMET, RUBBER 39 49821 2 BOLT, SOCKET HD. CAPSCR.
14 73132 1 BOOT, SPARK PLUG -M8-1.25 X 30MM
15 A1658 1 SPECIAL LOCK WASHER, 'A" 40 86999 1 GASKET, OIL FILTER
16 89685 2 GROMMET, RUBBER SUPPORT
17 22129 6 LOCK WASHER-M8 41 60108 1 SWITCH, OIL PRESSURE-
18 22127 1 HEX NUT-1/4"-20 10 PSI
19 57821 2 CAPSCR., HEX HD.- 42 75281 1 SWITCH, OIL TEMPERATURE
M8-1.25 X 40MM 43 Cl 085 2 SCREW, PHILIPS PAN HD.
20 59637 2 SCREW, TAPTITE MACH.-M3-.5 X 8MM
3/8"-16 X .75" 44 43182 2 LOCK WASHER-M3
21 21544 1 MOTOR, STARTER-12VOLT 45 70185 1 FILTER, OIL
22 40976 2 SOCKET HD. CAPSCR., 46 A7629 1 ENGINE, LONG BLOCK-
M8-1.25 X20MM GN410VSRV
23 SRV A6370 1 ASSY.-ELECTRONIC GOV. 47 82774 1 KEY, WOODRUFF 4 X 1 9 DIA.
24 A8875 1 ASSEMBLY, DIPSTICK & CAP 48 90388 1 TAPTITE, M6-1.00 X 12MM
25 A7299 1 OIL DRAIN/DIPSTICKTUBE
26 A9539 1 OIL DRAIN HOSE ASSEMBLY
