MTD 312-980I000 - Manual (Page 21)

Model 9801
PARTS LIST FOR MODEL 9801 SNOW THROWER
lEF.
NO. PART
NO.
CODE DESCRIPTION
REF.
NO.
PART
NO.
CODE DESCRIPTION
1 738-0561 Shid. Nut 1/4-20 Thd. 23 710-0600 Hex Wash. Hd. Self-Tap Scr.
2 738-0560 Shid. Bolt .374 Dia. x 1.375" Lg. 5/16-24 X .50" Lg.
3 741-0402 Hex Flange Plastic Bearing 24 736-0105 Bell-Wash. .40" I.D. x .88" O.D.
.38" I.D. 25 710-0427 Hex Bolt 3/8-16x2.0" Lg.*
4 05987 Clutch Grip Ass’y.—L.H. 26 784-5131B 638 Frame Cover
5 720-0220 Grip—Red 27 710-0555 Pilot Hex Scr. 3/8-16 x .88" Lg.
720-0180 Grip—Black 28 736-0105 Bell-Wash. .40" I.D. x .88" O.D.
6 747-0461 Lockout Rod 29 05500 Drive Clutch Brkt. Ass’y.
7 712-0267 Hex Nut 5/16-18 Thd.* 30 784-5133 Shifting Linkage Brkt. Ass’y.
8 736-0242 Bell-Wash. .34" I.D. x .88" O.D. 31 738-0129 Shid. Bolt .498 Dia. x 2.0" Lg.
9 731-0496 Plastic Plug 32 05518B Auger Clutch Brkt.
10 710-0487 Curved Carriage Bolt 33 732-0303 Extension Spring .38" O.D. x
5/16-18x2.0" Lg. 3.18" Lg.
11 749-0595 Upper Handle—L.H. 34 749-0406 Lower Handle—R.H.
12 726-0100 Push Nut 3/8" Rod 35 747-0356A Shifting Rod
13 720-0201A Knob 3/8" Rod 36 747-0696 Shift Handle
14 715-0138 Roll Pin .12 Dia. X. 631" Lg. 37 749-0596 Upper Handle—R.H.
15 05980 Chute Crank Ass’y. 38 05988 Clutch Grip Ass’y.—R.H.
16 747-0416A Eye Bolt 5/16-18x5.0“ Lg. 39 714-0104 Int. Cotter Pin 5/16" Dia.
17 741-0475 Plastic Bushing 40 736-0264 FI-Wash. .344" I.D. x .62" O.D.
18 749-0405 Lower Handle—L.H. 41 732-0193 Compression Spring
19 784-5451 638 Handle Panel Ass’y. 42 712-0429 Hex Ins. L-Nut 5/16-18 Thd.
20 732-0463 Extension Spring .75" O.D. 43 720-0218 Knob
X 5.0" Lg. 44 726-0247 Push Cap
21 712-0324 Hex Ins. L-Nut 1/4-20 Thd. 45 731-0473 Black Vinyl Grip
22 732-0184 Extension Spring .75" O.D.
X 5.0" Lg.
‘For faster service obtain standard nuts, bolts and washers locally.
If these items cannot be obtained locally, order by part number
and size as shown on parts list.
CODE: N notates a new part (not previously existing). A three digit
number is the color code. Specify color code as shown below if
color or finish is important when ordering parts, [i.e., 638 for Red
Finish].
NOTE
Specifications subject to change without notice or
obligation.
Color Codes
456—Radiant Tangerine 637—Black
460—Green Flake 638—Red
483—Charcoal Gray 640—Green
498—Yellow 646—CM Blue
499—Beige 657—Teal
629—Silver Flake
