MTD 24642-A - Manual (Page 11)

Models 642 and 645
PARTS LIST FOR LOG SPLITTER MODELS 642 and 645
.vO.
Part
No.
Color
Code
DESCRIPTION
New
Part
Ref.
No.
Part
No.
Color
Code
DESCRIPTION
New
Part
1 717-0407 Control Valve 32 712-0123 Hex Nut 5/16-24 Thd.*
2 727-0231 Return Stroke High Pressure 33 710-0409 Hex Bolt 5/16-24 x 1.75"
Hose Lg.*
3 727-0211 Forward Stroke High Pressure 34 750-0501 Filler Tube
Hose 35 750-0442 Spacer .75" I.D. x 1.12"
4 737-0161 Breather Valve O.D. X 1.56" Lg.
5 737-0173 Female Adapter 3/4-14 x 36 734-1016 Wheel Ass'y. Comp. 4.80/
1/4-18 N.P.T.F. 4.00 X 8
6 737-0153 Return Elbow 734-1017 Wheel Rim Ass'y.
7 726-0173 Hose Clamp 3/4" I.D. (Service Only)
8 727-0210 Return Hose 3/4" I.D. x 734-0872 Tire Only 4.80/4.00 x 8
2.62" Lg. (Service Only)
9 737-0172 Nipple 1/2-14 N.P.T.F. x 37 741-0107 Tapered Roller Bearing
1.5" Lg. (Service Only)
10 710-0117 Hex Bolt 5/16-24 x 1.00" 38 714-0121 Cotter Pin 5/32" Dia. x 1.00 I I
Lg. (Grade 5) Lg.*
11 738-0406 Return Stroke Stop Plunger 39 734-0873 Hub Cap (Service Only)
12 750-0428 Engagement Handle 40 712-0299 Hex Castle Nut 3/4-16 Thd.
13 08118 Grip 41 712-0123 Hex Nut 5/16-24 Thd.
14 747-0355 Cylinder Support Rod 42 736-0119 L-Wash. 5/16" I.D.*
(for 3-1/2" Dia.) (642) 43 714-0128 Sq. Key 1/4" x 1/4" x 1.00"
747-0354 Cylinder Support Rod Lg.
(for 4" Dia.) (645) 44 736-0119 L-Wash. 5/16" I.D.*
5 737-0152 High Pressure 90° Elbow 45 710-0157 Hex Bolt 5/16-24 X.75"
3/8 N.P.T. X 9/16-18 Lg.*
16 Cylinder Assy* (See Page 12 46 727-0228 Suction Hose (642)
for Breakdown) 727-0229 Suction Hose (645)
17 736-0169 L-Wash. 3/8" I.D.* 47 Sq. Key (comes with Ref.
18 712-0798 Hex Nut 3/8-16 Thd.* No. 48)
19 15234 Strainer Tube Ass'y- 48 717-0460 Pump with Sq. Key 1/8" x
20 15235 Complete Oil Tank & Beam 1/8" X 1.00" Lg. (642)
21 710-0624 Hex Bolt 5/16-24 X 1.50" 717-0461 Pump with Sq. Key 1/8" x
Lg- 1/8" X 1.00" Lg. (645)
22 712-0123 Hex Nut 5/16-24 Thd.* 49 712-0123 Hex Nut 5/16-24 Thd.*
23 736-0159 Fl.-Wash. .34 I.D. x .88" O.D. 50 736-0119 L-Wash. 5/16" I.D.*
24 732-0252 Compression Spring .64 O.D. 51 717-0462 Flexible Coupling
X .81 Lg. 52 710-0117 Hex Bolt 5/16-24 X 1.00" Lg.*
25 736-0160 Fl.-Wash. .53" I.D. x .94" O.D. 53 13295 Coupling Support Brkt. Ass'y.
26 738-0234 Shid. Bolt .500" Dia. x .295 54 710-0216 Hex Bolt 3/8-16 X.75" Lg.*
27 711-0198 Pivot Bushing 55 736-0105 Belleville Wash. 3/8" I.D.
28 747-0297 Engagement Rod .38 Dia. x 56 712-0107 Hex Cent. L.-Nut 1/4-20 Thd.
31" Lg. 57 710-0106 Hex Bolt 1/4-20 X 1.25" Lg.^
29 714-0507 Cotter Pin 3/32" Dia. x .75" 58 737-0171 90° Solid Male Adapter
Lg.* 59 770-0232 High Pressure Hose Ass'y.
30 13748 Frame Ass'y. 60 Engine
31 736-0119 L-Wash. 5/16" I.D.* 61 726-0132 Hose Clamp 1" I.D.
*For faster service obtain standard nuts, bolts and washers locally. If these items cannot be obtained locally, order by part
imber and size as shown on parts list.
The engine is not under warranty by the log splitter manufacturer. If repairs or service is needed on the
engine, please contact your nearest authorized engine service outlet. Check the "Yellow Pages" of your
telephone book under "Engines - Gasoline."
