MTD 242-630-000 - Manual (Page 15)

Model 630
PARTS LIST FOR MODEL 630 LOG SPLITTER
)lEF.
NO.
PART
NO.
CODE DESCRIPTION
REF.
NO.
PART
NO.
CODE DESCRIPTION
1 712-0359 Slotted Nut 3/4-16 Thd. 47 727-0311 Hitch Coupler
2 714-0162 Cotter Pin 5/32" Dia. x 1-1/4" Lg. 48 712-3000 Hex Ctr. L-Nut 3/8-16 Thd.
3 734-0873 Hub Cap 49 736-0116 FI-Wash. .635" I.D. x .93" O.D.
4 734-1016 Wheel Ass’y. Comp. 50 736-0169 L-Wash. 3/8" I.D.*
734-0872 Tire Only 51 736-0185 FI-Wash. .406" I.D. x .75" O.D.
734-1017 Rim Only 52 750-0497 Spacer 3/8" I.D. x .625" O.D.
721-0168 Bearing Seal Only 53 781-0162 Jack Stand
734-0255 Air Valve Only 54 781-0399 638 Tongue Tube
5 736-0351 FI-Wash. .76" I.D. x 1.5" O.D. 55 781-0370 Locking Rod
6 741-3028 N Bearing Cone 56 781-0398 Beam Support Ass’y.
7 736-0921 L-Wash. 1/2" I.D.* 57 723-0405 Filter Element
8 737-0192 90° Solid Male Adapter 58 723-0406 Filter Head
9 737-0238 Pipe Nipple 1/2 NPT 59 726-0146 Adj. Hose Clamp
10 741-3029 N Bearing Cup 60 727-0443 Return Hose 3/4" I.D. x 44" Lg.
14 710-1010 Hex Bolt 1/2-20 x 3" Lg. 62 781-0404 Vertical Beam Ass’y.
(Grade 8) 66 714-0470 Cotter Pin 1/8" Dia.
15 710-1018 Hex Bolt 1/2-20 X 2.75" Lg. 68 738-0805 Hinge Pin 1/2 x 4.8" Lg.
(Grade 8) 73 710-0117 Hex Bolt 5/16-24 X 1" Lg.
16 710-1032 Hex Bolt 3/8-24 x 1.5" Lg. 74 710-0237 Hex Bolt 5/16-24 X .62" Lg.
17 712-0239 Hex L-Nut 1/2-20 Thd. 75 710-0968 Hex Bolt 5/16-24x5" Lg.
18 712-0333 Hex Nut 1/2-20 Thd. 76 712-0123 Hex Nut 5/16-24 Thd.
19 712-3001 Hex Jam Nut 3/8-24 Thd. 77 714-0122 Sq.-Key 3/16" x .75"
(Grade 5) 78 717-0891
Flexible Coupling 5 ET ^
21 732-0583 Comp. Spring 4" Lg. 79 717-0887A Two Volume Pump
23 781-0323B Wedge Ass’y. 80 719-0278 Coupling Shield
24 781-0345A Pusher Back Plate 81 726-0132 Hose Clamp 5/8"
25 781-0350A Fixed Side Gib 82 727-0448 Suction Hose 3/4" I.D. x 17" Lg.
^26 781-0351 Adjustable Gib 83 727-0324 High Pressure Hydraulic Hose
27 781-0352A Adjustable Gib Shim
28 781-0356 Floating Gib Plate 84 736-0119 L-Wash. 5/16" I.D.*
29 714-0203 External Cotter Pin 85 781-0097 Rear Coupling Support Brkt.
30 715-0206 Cylinder Mounting Pin 86 781-0098 Front Coupling Support Brkt.
31 717-0885B 638 Hydraulic Cylinder 88 710-0409 Hex Bolt 5/16-24 X 1.75" Lg.
32 717-0899 Control Valve 89 — Engine
33 727-0323 Metal Pressure Tube 91 737-0236 L-Vent Pipe Plug
35 737-0153 Return Elbow 92 735-0639 Spark Plug Boot
36 737-0279 Adapter 95 781-0501 638 Tank Ass’y.
37 737-0235 3/4" Hose Barb. 96 720-0235 Grip
39 710-3066 Hex Bolt 3/8-16x2.75" Lg. 97 747-0583 Control Handle
(Grade 8) 98 732-0194 Spring Pin
40 710-0411 Hex Bolt 3/8-16x4" Lg. 99 781-0168A Stripper Plate
41 710-3080 Hex Bolt 3/8-16 X 4" Lg. 100 710-3144 Hex Bolt 3/8-16 X 2.0" Lg.
(Grade 5) (Gr. 5)
42 711-0813 Clevis Pin 5/16x2.5" Lg. 101 712-0430 Hex L-Nut 3/8-16 Thd.
43 712-0375 Hex L-Nut 3/8-16 Thd. 102 750-0743 Spacer 1/2" I.D. x .68" Lg.
44 712-0798 Hex Nut 3/8-16 Thd.* 103 721-0168 Bearing Seal Only
45 713-0433 Chain—^Tow Hitch 104 736-0262 Fl-Wash. 3/8" I.D. x .87" O.D.
46 715-0116 Roll Pin
|0
*For faster service obtain standard nuts, bolts and washers locally.
If these items cannot be obtained locally, order by part number
and size as shown on parts list.
638-Red
CODE: N notates a new part (not previously existing). A three digit
number is the color code. Specify color code as shown above if
color or finish is important when ordering parts, [i.e., 638 for Red
Finish].
NOTE: The engine is not under warranty by the
log splitter manufacturer. . .If repairs or service
is needed on the engine, please contact your
nearest authorized engine
service outlet. Check the
“Yellow Pages” of your
telephone book under
“Engines-Gasoline.”
