Section 6 — Exploded Views and Paris Lists
Guardian Liquid-cooled 8 kW Generators
Compartment - Drawing No. C2436-B
’’EM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION
1 *02433 1 CORNER POST, LH. REAR 24 C2755P 1 ROOF, TOP (INSUL.)
2 *02434 1 CORNER POST, RH. REAR 25 C2755M 1 DOOR, RIGHT SIDE (INSUL)
3 A3443 1 PANEL. REAR BOTTOM 26 C2755G 1 AIR DUCT, BOTTOM (INSUL.)
4 A3444 1 PANEL, REAR TOP 27 C2755H 1 AIR DUCT. FRONT RH,
5 A3445 3 PANEL. SIDE (INSUL.)
6 A3446 1 PANEL, RH. SIDE BOTTOM 28 C2755J 1 AIR DUCT, LH. SIDE (INSUL.)
7 A3447 1 CORNER POST, LH. FRONT 29 C2755K 1 AIR DUCT, FRONT LH.
8 A7198 1 CORNER POST, RH. FRONT (INSUL.)
9 A3449 2 DOOR, SIDE 30 C2755L 1 AIR DUCT, RH. SIDE (INSUL.)
11 A3451 1 PANEL, FRONT TOP 31 22473 50 FLAT WASHER-M6-1/4"
12 A7197 1 PANEL, FRONT 32 22097 32 LOCK WASHER-M6-1/4"
13 A3453 1 DOOR, REAR 33 22127 6 NUT. HEX-1 M"-20
14 A3454 1 TOR ROOF 34 49813 18 NUT, HEX-M6-1.0
16 *02435 1 DUCT, RH. REAR CORNER 35 42568 18 CAPSCR..HEX HD.-M6-1,0 x 20
POST LONG
*C2435A 1 DUCT, LH. REAR CORNER 36 67577 16 SPEED NUO1/4"-20
POST 37 22413 16 CAPSCR., HEX HD,-1/4"-20 x 1
17 C2755A 1 PANEL, REAR BOTTOM 38 67042 4 LATCH & CAM
(INSUL.) 39 78115 4 WASHER. SELF LOCK/DOME
18 C2755B 1 DOOR, REAR (INSUL.) 40 A3133A 2 HINGE, SLIP-MALE L.H.
19 C2755C 1 DOOR, FRONT (INSUL.) A3133B 2 HINGE, SLIP-FEMALE L.H.
20 C2755D 2 CORNER POST, FRONT A3133C d HINGE, SLIP-MALE R.H.
(INSUL.) A3133D d HINGE, SLIP-FEMALE R.H,
21 C2755E 1 DOOR, LEFT SIDE (INSUL.) 41 A3359 40 BHSCS-M6 X 16 S.S.
22 C2755F 4 PANEL, SIDE (INSUL.) 42 A3360 40 SHAKEPROOF, INT.-M6 S.S.
23 C2755N VENTURI, TOP (INSUL.)
FOR REF. ONLY (SEE 02438 CONTROL PANEL FOR
DE \lLSi
ör-iVA/pan S V «=; ft {= m «=:. inrt.
