Speed Selector and Wheels
Models 924050, 51,71,73,74,75, 76,77
ITEM
N0
PART
N0 DESCRIPTION QTY
ITEM
NO
PART
NO DESCRIPTION QTY
1 57086 Snap Ring 1/2 1 22 71037 Inner Tube 8 x 4.00 (50,51,74) 2
2 75096 Knob 1 71050 Inner Tube 6 x 4.10/3.50 (75) 2
3 24448 Rod 1 71087 Inner Tube 8 x 6.50 (71,73) 2
4 83184 Extension Spring 1-1/16 1 71052 Rim 6” OD (75) 2
5 24443 Pivot 1 71076 Rim 8 X 4.80/4.00 (50,51,74,77) 2
6 65042 Two Way Lock Nut 5/16-18 Gr A 3 71077 Rim 8 x 6.50 (71,73,76) 2
7 65040 Center Lock Nut 1/4-20 1 71021 (A)Turf Saver Tire 8 x 6.50 (71,73 2
8 59132 Cap Screw 1/4-20 x 1 1 71046 (A)Turf Saver Tire 6 x 4.10/3.50 (75) 2
9 59131 Cap Screw 5/16-18x2-1/4 1 71052 (A)Turf Saver Wheel w/Tire (71,73) 2
10 67024 Cotter Pin 1/8 X 3/4 1 71082 (A)Turf Saver Tire (50,51,74) 2
11 24442 Upper Shift Rod 1 71151 (A)Turf Saver Wheel w/Tire (50,51,74) 2
12 65031 Nut 5/16-24 1 71165 (A)Turf Saver Wheel w/Tire (75) 2
13 67001 Cotter Pin 3/32 X 3/4 3 71216 (B)Snow-Hog Tire 16 x 6.50-8 (71,73,76) 2
14 24493 Shift Link 2 71217 (B)Snow-Hog Wheel w/Tire 2
15 12151 Cievis Pin 2 6.50 (71,73,76)
16 24441 Lower Shift Rod 1 71218 (B)Snow-Hog Tire 4.80/4.00-8 (50,51,77) 2
17 24232 Shift Arm Lever 1 71219 (B)Snow-Hog Wheel w/Tire 2
18 24588 Frame (50,51,73,77) 1 4,50/4.00 X 8 (50,51,77)
24502 Frame(71) 1 23 3377 Hub Cap 1
24436 Frame (74,75) 1 24 74063 Taptite 1/2-20 X 5/8 8
24589 Frame (76) 1 25 59039 Cap Screw 5/16-18 x 1/2 1
19 24430 Bottom Cover 1 26 24231 Shift Lever Bracket 1
20 35169 Spindle Cup 1 27 74014 Taptite 5/16-18 X 1/2 7
21 10366 Pushnut (50,51,71,73) 1 28 59136 Cap Screw 5/16-18 x 3 1
67014 Cotter Pin 1/8 X 1-1/4 (74,75) 1 29 24115 Spacer 1
30 75167 Hole Plug 1
(A)924050 S/N <085100
924051 S/N <000700
924071 S/N <008200
924073 S/N <012400
(8) 924050 S/N 085101)
924051 S/N 000701)
924071 S/N 008201)
924073 S/N 012401)
