Ariens SNO-THRO 924 - Manual (Page 11)

Engine and Belt Drive
Models 924050, 51, 71, 73, 74, 75, 76, 77
ITEM
NO
m i
NO OESCRIPTION QTY
ITEM
NO
PART
NO DESCRIPTION OTY
Order Engine and Parts from 20 65077 Nylon Lock Nut 5/8-18 1
Engine Manufacturers Dealer 21 72066 V-Belt (50,51,73,74,77) 1
1 82196 5 HP Engine (74) 1 72098 V-Belt (75) 1
Tecumseh HSK50-65496 72131 V-Belt (71,76) 1
82236 7 HP Engine (75) 1 22 70060 Rib Neck Bolt 5/16-18 x 7/8 3
Tecumseh HSK70-13021 OK 23 73070 Pulley 1
82197 (A)8 HP Engine (50,51) 1 24 24236 Belt Retainer (71,73,76,77) 1
Tecumseh HMSK80-155276J 25 5S028 Cap Screw 1/4-20 x 1/2 2
82214 (B)8 HP Engine (50,51) 1 26 65040 Center Lock Nut 1 /4-20 2
Tecumseh HMSKBO-155276K 27 72086 V-Belt (50,74) 1
82233 (C)8 HP Engine (50,51,77) 1 27 72108 V-Belt (73,75,77) 1
Tecumseh HMSK80-155316M 72130 V-Belt (71,76) 1
82173 (A)10 HP Engine (73) 1 28 24389 Hub 1
Tecumseh HMSK100-159024J 29 65078 Flange Whiz-Lock Nut 5/16-18 3
82215 (B)10 HP Engine (73) 1 30 65042 Two Way Lock Nut 5/16-18 Gr A 2
Tecumseh HMSK100-159024K 31 64007 Washer .307/.327 x .734 x .065 1
82255 (C)10 HP Engine (73) 1 32 24574 Idler 2
Tecumseh HMSK100-159119M 33 12131 Bearing Spacer 1
82174 (A)11 HP Engine (71) 1 34 59069 Cap Screw 5/16-18 x 1-1/4 2
Briggs & Stratton 252416-0632-01 35 24348 Idler Arm 1
82235 (B)11 HP Engine (71) 1 36 24354 Clevis Pin 1
Briggs & Stratton 252416-0739-01 37 24347 Bracket 1
82275 12 HP Engine (76) 1 38 74015 Taptite 1/4-20 X 3/8 5
Tecumseh OHSK 120-222001 39 67001 Cotter Pin 3/32 X 3/4 1
2 25208 Hex Cap (50,51,73) 1 40 24353 Return Clip 1
3 12222 Nipple (50,51,73) 1 41 74054 Taptite #10-24 X 3/8 2
4 10485 Street Elbow (50,51,73) 1 42 24428 Activating Shaft 1
5 35101 Tube (71) 1 43 83172 Extension Spring 3-3/8 1
6 30199 Hose Clamp (71) 1 44 55037 Flange Bushing 1
7 35105 Drain Lock (71) 1 45 11031 Spacer 1
8 35077 Bushing (71) 1 46 24537 Idler Arm 1
9 74049 Taptite 1/4-20 X 1/2 2 47 83094 Extension Spring 3-1/16 1
10 64065 Washer .263/.273 x .562 x .046 1 48 67004 Cotter Pin 1/8 X 1” 1
11 24406 Belt Cover 1 49 64052 Washer .380/,385 x .812 x 24 Ga 1
12 24253 Belt Finger (50,51,73,74,75) 1 50 10260 Wave Washer 1
24505 Belt Finger (71) 1 51 24507 R.H. Support 1
13 64002 Washer .370/.390 X .875 x .083 5 52 24501 L.H. Support 1
14 63032 Lock Washer 5/16 2 53 63003 Lock Washer 5/16 4
15 59053 Cap Screw 5/16-24 x 3/4 Gr 5 2 54 65015 Nut 5/16-18 4
16 60012 Set Screw 5/16-18x3/8 4 55' 24597 Plate 1
17 24021 Engine Pulley ((75) 1 56 75097 Knob W/10-24 1
24357 Engine Pulley (50,51,71,73,74,76,77) 1 Tapped Metal Insert (71)
18 66018 Straight Key 1/4 x 1-3/4 x 1/4 1 57 24587 Spacer 4
19 73049 Pulley 1
(A) 924050 S/N <063957
924051 S/N <000530
924071 S/N <008200
924073 S/N <007797
(B) 924050 S/N 064100) <085100
924051 S/N 000600) <000700
924071 S/N 008201)
924073 S/N 007901X012400
(C) 924050 S/N 085101)
924051 S/N 000701)
924073 S/N 012401)
924077 S/N 000101)
9
