Ariens SNO-THRO 924 - Manual (Page 13)

Reduction Drive
Models 924050, 51, 71, 73, 74, 75, 76, 77
i
ITEM
NO
PART
NO DESCRIPTION QTY
ITEM
NO
PART
NO DESCRIPTION QTY
1 74015 Taptite 1/4-20 X 3/8 6 28 58029 Roll Pin 5/32 X 1" 1
2 24077 Shaft Support 2 29 58009 Roll Pin 1/8 X 1” 1
3 12023 Bearing Retainer (74,75) 2 30 24074 Pinion Chain 1
24363 (A)Bearing Retainer (50,51,71,73) 2 31 524002 Pinion & Sprocket (75) 1
24578 (B)Bearing Retainer (50,51,71,73,76,77) 2 524032 Pinion & Sprocket (50,51,71,73,74,76,77) 1
4 54136 (A)Ball Bearing (50,51,71,73) 2 32 55026 Flange Bushing 2
54177 (B)Ball Bearing (50,51,71,73,76,77) 2 33 13136 Zerk Fitting 1
55030 Bushing (74) 2 34 10211 Spur Gear (75) 1
55039 Bushing (75) 2 24396 Spur Gear (74) 1
5 64033 Washer .750/.760 x 1.375 x .125 2 524053 Differential (50,51,71,73) 2
64170 Washer 1.135/1.145 X 1.718 X .134 2 35 524054 L.H. Axle (71,73) 1
6 70011 Rib Neck Bolt 1/4-20 x 5/8 8 524055 L.H. Axle (50,51) 1
70058 Rib Neck Bolt 1/4-20 x 1/2 8 36 55057 Sleeve Bushing 1
7 65056 Flange Whiz-Lock Nut 1/4-20 8 37 63025 Lock Washer 1/4 1
8 24045 Hex Shaft (50,51,71,73,74) 1 38 22093 Zerk Fitting 2
24338 Hex Shaft (75) 1 39 55029 Sleeve Bushing 1
9 66015 Woodruff Key 1/8 x 5/8 x 1/4 1 40 58042 Groove Pin 1/4 X 1-3/4 1
10 10276 9 Tooth Sprocket 1 41 524059 Lockout Hub Assembly (50,51,71,73) 1
11 12078 Idler Chain (75) 1 42 58032 Roll Pin 3/32 X 1” 1
24073 Idler Chain (50,51,71,73,74) 1 43 10375 Knob 1
12 64003 Washer .526/.546 x 1.062 x .095 2 44 10372 Lockout Hub 1
13 3085 Bearing Flange 1 45 83007 Compression Spring 1” 1
14 54080 Radial Bearing 1/2 I.D. 1 46 10374 Pin 1
15 24141 Bearing Flange 1 47 24323 Wheel Hub (75) 2
16 65094 Twin Whiz-Lock Nut #10-24 4 24398 Wheel Hub (74) 2
17 65054 Center Lock Nut 1/2-20 1 48 64033 Washer.750/.760 x 1.375 x .125 2
18 65018 Nut 3/8-16 2 64036 Washer .875/.885 x 1.380 x .062 2
19 63014 Lock Washer 3/8 2 49 58003 Roll Pin 3/16 X 1-1/4 2
20 64093 Washer .380/.385 x .812 x .062 2 50 67014 Cotter Pin 1/8 X 1-1/4 2
21 24475 Reduction Shaft 1 51 66011 Feather Key 3/16 x 1-1/4 x 3/16 2
22 55040 Sleeve Bushing 2 52 24322 Axle Shaft (75) 1
23 524052 Reduction Sprocket 1 24397 Axle Shaft (74) 1
24 24366 Shaft Support (50,51,71,73,74,76,77) 1 53 66008 Woodruff Key 1/4 x 7/8 x 3/8 1
24339 Clutch Stop (75) ^ 1 66012 Woodruff Key 1 / 4 x 3 / 4 x 5 / 1 6 1
2 5 74052 Taptite 1/4-20 X 1/2 ~ 1 54 58030 Roll Pin 3/16 X 1-1/2 1
26 64039 Washer .625/.635 x 1.005 x 24 Ga 5 55 24371 R.H. Axle (71,73) 1
27 24367 Pinion Shaft 1 24409 R.H. Axle (50,51) 1
(A) 924050 S/N
924051 S/N
924071 S/N
924073 S/N
(B) 824050 S/N
924051 S/N
924071 S/N
924073 S/N
<085100
<000700
<008200
<012400
085101)
000701)
008201)
012401)
11
