Auger/Impeller
Models 924050, 51, 71,73,74, 75, 76,77
ITEM
NO
PART
NO
DESCRIPTION
QTY
ITEM
NO
PART
NO
DESCRIPTION
QTV
1 524061
(A) Deflector (50,73,74,75)
1
31
22093
Zerk Fitting
4
531144. (B)Deflector (71,73,76,77)
1
32 524013
32” R.H. Auger (73)
1
2
10198
Cap
1
524014
32” L.H. Auger (73)
1
3
75083
Knob
1
524039
24” R.H. Auger (50,74,75)
1
4
24461
Chute Control Crank
1
524040
24” L.H. Auger (50,74,75)
1
(50,73,74,75,76,77)
524063
28” R.H. Auger (77)
1
24508
Chute Control Crank (71)
1
524064
28” L.H. Auger (77)
1
5
67004
Cotter Pin 1/8
X
1” (50,74,75)
1
535034
36” R.H. Auger (71,76)
1
§7010
Hair Pin (71,73)
2
535035
36” L.H. Auger (71,76)
1
6 524050
Universal Joint
2
33 510015
Shear Bolt w/Nut
2
7
58034
Roll Pin 1/8
X
3/4
3
34
64046
Washer 1.005/. 1.015 x 1.505 x .062
2
8
24346
Rod (50,73,74,75)
1
35
24374
Bearing Support
2
24504
Rod (71)
1
36
65056
Flange Whiz-Lock Nut 1/4-20
6
9
24434
Chute Crank Bracket
1
37
55035
Flange Bushing
2
(50,73,74,75,76,77)
38
64047
Washer .506/.516 x 1.441 x .125
2
24503
Chute Crank Bracket (71)
1
39
63006
Lock Washer 1/2
2
10
10494
Worm Shaft (50,73,74,75)
1
40
59024
Cap Screw 1/2-13 x 1”
2
24514
Worm Shaft (71,73,76,77)
1
41
83164
Extension Spring 5-1/4
1
11
10260
Wave Washer (50,73,74,75)
1
42
65040
Center Lock Nut 1/4-20
4
13202
Wave Washer (71,73,76,77)
1
43
24405
Arm Extension (50,74)
1
12
24500
L.H. Worm Gear
1
44 524048
Arm w/Lining
1
13
64168
Plastic Washer .390 x .875 x .062
1
45
24481
Clevis Pin
1
14
62034
Carriage Bolt 5/16-18 x 3/4
1
46
67039
Cotter Pin 1/16
X
3/4
1
15
22123
Worm Clevis
1
47
22178
Brake Lining
1
16
63035
Lock Washer 3/8
1
48
68067
Oval Rivet 3/16
X
7/16
2
17
63023
Lock Washer 5/16
1
49
59080
Cap Screw 1/4-20 x 5/8
1
18
65015
Nut 5/16-18
3
50
70026
Retainer Nut
2
19 524036
24” Auger/Impeller Housing (75)
1
51
70031
Flange Whiz-Lock Screw 3/8-16 x 3/4
2
524037
24” Auger/Impeller Housing (50,74)
1
52
10142
Bearing Flange (50,74,75)
1
524038
32” Auger/Impeller Housing (73)
1
31859
Bearing Flange (71,73,76,77)
1
524043
36” Auger/Impeller Housing (71,76)
1
53
74069
Taptite #10-24
X
1/2
8
524065
28” Auger/Impeller Housing (77)
1
54
24590
Chute Clamp
4
20
24599
Runner (50,74,75)
2
55
67001
Cotter Pin 3/32
X
3/4
1
30755
Runner (71,73,76,77)
2
56
69137
Control Cable (71,73,76,77)
1
21
64002
Washer .370/.390 x .875 x .083
15
57
61065
Machine Screw #10-32 x 1/2
1
22
65039
Two Way Lock Nut 3/8-16 Gr A
5
58
75137
Tee Handle (71,73,76,77)
1
23
62013
Carriage Bolt 3/8-16 x 1”
2
59
24535
Deflector Control Bracket
1
24
62010
Carriage Bolt 3/8-16
X
3/4
5
(71,73,76,77)
25
54052
Ball Bearing (71,73)
1
60
24548 (A) Discharge Chute (71,73,76,77)
1
54063
Radial Bearing (50,74,75)
1
24499 (B) Discharge Chute (50,73,74,75)
1
26
3017
Bearing Flange (50,74,75)
1
61
65001
Jam Nut 3/8-16
2
31860
Bearing Flange (71,73,76,77)
1
65039
Two Way Lock Nut 3/8-16 Gr A
2
27
70058
Rib Neck Bolt 1/4-20
X
1/2
6
62
64043
Washer .401/.421 x .812 x .065
2
28
10164
Scraper Blade (50,74,75)
1
64067
Washer .390 x .875 x 7 Ga
1
24373
Scraper Blade (73)
1
63
64168
Plastic Washer .390 x .875 x .062
1
24592
Scraper Blade (77)
1
64
59023
Cap Screw 3/8-16 x 3/4
2
35192
Scraper Blade (71,76)
1
65
24496
Cable Guide (71)
1
29
62033
Carriage Bolt 5/16-18 x 5/8
5
66
63003
Lock Washer 5/16
1
30
65042
Two Way Lock Nut 5/16-18 Gr A
13
67
69170
Cable Tie
1
y
y
(A) 924073 S/N <015900
(B) 924073 S/N 015901>
