Ariens SNO-THRO 924 - Manual (Page 21)

Aluminum
Models 924050, 74,75
ITEM
NO
PART
NO DESCRIPTION QTY
ITEM
NO
PART
NO DESCRIPTION QTY
i 58037 Roll Pin 1/4 X 1-3/4 2 14 58030 Roll Pin 3/16 X 1-1/2 2
2 24237 Impeller 1 15 55122 Flange Bushing 2
3 56047 0-Ring 3/4 ID 1 16 55111 Flange Bushing 1
4 55112 Flange Bushing 1 17 64166 Washer 1.002/1.012 x 1.5 2
5 32103 Thrust Collar 1 18 58069 Groove Pin 5 / 1 6 x 1 - 7 / 1 6 1
6 58045 Groove Pin 3 / 1 6 x 1 - 1 / 4 1 1 9 32038 Gasket 1
7 66001 Woodruff Key 3/16 X 7/8 X 3/8 1 20 24380 R.H. Gear Case Half 1
8 524026 Worm & Gear Shaft Set 1 21 65056 Flange Whiz-Lock Nut 1/4-20 4
9 24379 L.H. Gear Case Half 1 22 74016 Taptite 3/8-16 X 1/2 1
10 62001 Carriage Bolt 1/4-20 x 1-1/4 2 23 24383 Auger Shaft 1
11 56061 Sean” ID , 2 24 524030 Gear Case (Complete) 1
12 74027 Taptite # 1 0 - 2 4 x 3 / 4 2 Requires 2 Oz. Liquid Grease
13 62054 Carriage Bolt 1/4-20 x 7/8 2 25 72 8 Oz. Tube Liquid Grease 4
19
