CHECK TRANSMISSION OIL LEVEL
The hydrostatic transmission, differential and hydraulic
lift system (if the tractor is so equipped) all operate from a
common oil reservoir.
A
CAUTION: Proper oil level is essential for full braking
effect and protection against severe damage to the
transmission.
Use the following procedure to check the transmission oil
level:
1. Be sure tractor is level and tires are inflated properly.
2. Wipe dirt from around the oil level and filler plug. Figure
6
A.
3.
With engine running, remove plug. Oil level is correct when
it is at the top of the filler elbow as shown in Figure
6
A.
4: If necessary, use a small funnel to add sufficient ARIENS FILL FUEL TANK
10W-30 Gard-N-Yard oil to bring the oil up to the proper Fill fuel tank with regular grade gasoline. Do not use
level. Replace plug.
premium gasoline.
Be very careful to prevent dirt and foreign materials from CHECK TIRE PRESSURE
entering the oil reservoir when checking the oil.
, ,
Inflate tires to pressures shown in the chart below. Use a
A
IMPORTANT: Do not push or tow tractor long
l°w pressure tire gauge for accurate readings.
distances as internal transmission damage could re
sult Load tractor on truck or trailer when delivering
to purchaser.
TIRE SIZE
LOADING
Light
Medium
Heavy
Front
(Lawn Work)
(Sno- Thro)
16
X
6.50
X
8
.8 p.s.i.
12 p.s.i.
16 p.s.i.
Rear
23
X
10.50
X
12
(Lawn Work)
6 p.s.i.
(Rotary-Tiller)
8 p.s.i.
10
p.s.i.
Figure 5A
TRANSMISSION
OIL
FILLER PLUG
CHECK SAFETY INTERLOCK SYSTEM
To make sure that the safety interlock system has not become
disconnected or damaged in shipment, check to see that the
tractor will not start unless:
a. The shift lever is in the PARK/START position
b. Implement Power Control Switch is in the OFF (In)
position.
If the engine starts with above controls in any other position,
the safety interlock must be corrected before delivery.
DELIVERY
Using the Owner's Manual as a guide, instruct the cus
tomer as follows:
1. Instruct the customer on the
operation of the tractor.
4
. Explain maintenance and adjustment instructions.
Emphasize safety and discuss the
safety information in the 5. Demonstrate how to mount and dismount attachments.
Owner's Manual.
6
. Make certain the customer has his Owner's Manual.
2. Advise customer to change oil in the engine crankcase
7. Explain Ariens Warranty Policy. Fill out and
return
after the first five hours of operation.
Ariens Warranty Registration Card.
3. Explain how to perform the recommended lubrication and
periodic service.
- 4 2 -
