SINGER
Zigzag stitching
I
Before moving selector, make sure needle is fully raised,
Needle position selector
Most of your zigzag stitching will be done with the
needle in the centre ( i ) position.
Left(
¿3
) and right (
ci
) settings are used for special
stitch placement.
Stitch width selector
To produce any of the zigzag stitches, the stitch width
selector is moved from its straight position ( |
) to any
of its other positions. The further you move the selector
lever toward the right, the wider your stitch will be.
Adjusting stitch length
Any stitch length setting from 1 to 5 will give you a more
or less open zigzag stitch.
The higher the number, the more open, or further apart
your stitches will be.
The area between 0 and 1 on the dial is used for satin
stitching, a series of closely spaced plain zigzag stitches
that form a smooth satin-like surface.
A
r
--- Ì
d
A ci
r
2 AAAM
3
AAAAA
4/WW\
5/WW\
Q
