Fig. 3
WtNDING THE BOBBIN
Disengage the wheel, (Fig. 3.)
Place thread on spool pin A
(Fig. 4)and draw thread through
thread guide on top cover B
(Fig. 4.) Bring thread across the
machine to bobbin winder thread guide on bed plate C.
Pull thread under and up left to right.
Wind a few turns of thread by hand around the bobbin and place
bobbin on bobbin winder spindle.
Press on lever marked PUSH and bobbin winder will engage the hand
wheel.
Start to fill bobbin by running the machine at normal speed to allow
the bobbin to wind evenly and firmly. The bobbin winder will stop
and disengage itself, when the bobbin is about eighty percent filled.
NOTE ; Do not fail to
tighten the brake button
on the hand wheel
iclock-wise) to re-engage
the sewing mechanism.
Fig. 4
10
