SECTION V
OPERATING INSTRUCTIONS
30. 50. 75 & 100 lb. Models
A. MECHANICAL COIN METER CONTROLS (non-computer)
1. The controls of a coin-metered model dryer consist of:
Component
Coin Meter
Heater Selector Switch
"Pushto Start" button
Function
Permits the dryer to be started after the insertion of coins. The meter
also controls the timing of the drying and cooling cycles.
Controls temperature of a drying cycle.
Safety Device which must be manually "pressed" to start the dryer.
Whenever the dryer is stopped by opening the main door during a cycle,
the "Push to Start" button must be pressed to restart the dryer.
Indicator Light Lights to indicate that the dryer is in the drying or cooling cycle.
2. Operating Sequence
a. Insert coin. Rotate knob fully clockwise and release after coin is accepted.
b. Make temperature selection in accordance with the type of material being dried.
c. To start unit, press "Push to Start" button.
NOTE: Main door must be closed.
d. The dryer will start. The heat circuit activates.
e. During operation, the heat circuits will continue to be active until the thermostat controlling the
"temperature e selected" is satisfied and opens. The dryer will continue to operate under these conditions
until the dryer enters the cool-down cycle or until the completion of metered time.
Time can be accumulated at any time by the insertion of more coins. Cool-down time is not accumulative.
The dryer can be stopped at any time by opening the main door. While the door is open, the meter will
continue to count time. Continuation of the cycle will only resume after the door is closed and the "Push
to Start" button is again depressed.
21
