27. SPECIFICATION
Item
Specification
Sewing speed
1,300 spm maximum
Stitch length (feed amount)
1 ~ 4mm (standard: rolled hemming F - 2, ordinary overedge 3.0)
Differential feed ratio
1:0.7 ~ 1:2 (with differential feed machine)
Overedge stitch width
Rolled hemming 1.5mm, ordinary overedge 3.0 ~ 6.7 mm
(standard 3.5mm)
Needle bar stroke
27mm
Presser foot rise
4.5mm
Needle
Rolled hemming: Singer Cat. No. 2022 #11
Ordinary overedge: Singer Cat. No. 2022 #11, #14
Model
14SH644 14SH654
Number of threads
Machine dimensions (mm)
3,4 3,4
Width
329 329
Depth
270 270
Height
265 265
Weight (Kg)
6.0 6.2
47
