( How to Exchange Light Bulb"
A
j\ Danger;
Always unplug before relamping
Light bulb is available at your Singer shop. Take
oid bulb to the Singer shop and ask for same bulb.
If voltage indicated on the electrical rating plate of
your machine is 110 - 127V, ask for light bulb
conforming to following specification.
- Bayonet type:
. Glass shape:
. Lamp cap:
. Overall length;
110 ~ 127V, 15W
T-20
BA15D/19
48 ~ 58mm
Remove light cover screw and while pushing the
cover lightly to the rear, swing cover to the left and
remove from machine as shown in the illustration.
Turn bulb to the left to remove. To replace the bulb,
push bulb into the socket and turn to the right.
A
A
Caution:
Be sure the light bulb has cooled off before
changing with a new one.
Warning;
Replace the light cover first before connecting
the power line plug.
If voltage indicated on the electrical rating plate of
your machine is 200 ~ 240V, ask for light bulb
conforming to following specification.
- Edison type (screw type); 200 ~ 240V, 15W
. Glass shape: T-22
. Lamp cap:
E14
. Overall length: 56mm
Remove light cover screw and while pushing the
cover lightly to the rear, swing cover to the left and
remove from machine as shown in the illustration.
Turn bulb to the left to remove. To replace, screw
bulb into socket turning it to the right.
44
