SEARS CRAFTSMAN 26" SNOW THROWER MODEL NO. 247.886700
Repair Parts
KEY
NO.
PART
NO.
DESCRIPTION
KEY
NO.
PART
NO.
DESCRIPTION
1 784-5384 Frame Ass’y- 47 748-0327 Shift Arm Extension
2 784-5386 Shift Support 48 736-0256 FI-Wash. .63" I.D. x .93" O.D,
3 784-5382 Back Plate Ass’y. 49 710-0289 Hex Bolt V 4-20 X .5" Lg.'
4 736-0329 L-Wash. 1 / 4 " I.D.* 50 710-0152 Hex Bolt 3/8-24 x 1" Lg.*
5 712-0287 Hex Nut V 4-20 Thd.* 51 710-0603 Hex Wash. Hd. B-Tap Scr.
6 710-0599 Hex TT-Tap Scr. %-20 x .5" Lg. 5/16-18 x .5"
7 710-0623 Hex Self-Tap Scr. 3/8-16 x .75" 53 712-0241 Hex Nut 3/8-24 Thd.*
Lg-
54 712-0267 Hex Nut 5/16-18 Thd.*
8 736-0217 L-Wash. 3/8" I.D. 55 712-0116 Hex L-Nut 3/8-24 Thd. Gr. 5
10 714-0143 Kwick Pin 56 720-0223 Grip
11 734-1417 Wheel Ass’y- Comp. 57 736-0119 L-Wash. 5/16" I.D.*
734-1375 Tire Only 58 736-0169 L-Wash. 3/8" I.D.*
12 734-0255 Air Valve 59 738-0372 Shoulder Spacer
13 734-1145 Him Only 60 784-5318 Side Arm Ass’y.—R.H.
15 741-0401 Sleeve Brg. .755" I.D. 61 784-5319 Side Arm Ass’y.—LH.
16 736-0287 FI-Wash. .793" I.D. 62 784-5321 Pivot Handle Ass’y.
17 736-0315 FI-Wash. .75" I.D. 63 784-5389 Position Selector Plate
I
ia
750-0442 Spacer .75" I.D. 64 746-0692 Clutch Cable 25.5" Lg.
20 710-0118 Hex Bolt 5/16-18 X .75" Lg.' 65 746-0693 Auger Cable 25.5" Lg.
21 710-0442 Hex Bolt 5/16-18 X 1.5" Lg.' 70 710-0188 Set Scr. V4-28 x .18"
22 710-0603“ Hex Wash. Hd. B-Tap Scr, 71 710-0237 Hex Bolt 5/16-24 x .62"
5/16-18 X .5" Lg,* 73 710-0502A Hex L-Wash, TT-Tap Scr. 3/8-16
23 710-0459 Hex Bolt 3/8-24 x 1.5" Lg. 74 710-0938 Set Scr. V 4-28 x .25"
24 710-0874 Hex Bolt 5/16-18 X 1.25" Lg.* 75 711-0769 Stud 3/8-16 X 3.37" Lg.
25 711-0640 Stud 3/8-16 X 2.75" Lg. 76 712-0123 Hex Nut 5/16-24 Thd.*
26 712-0241 Hex Nut 3/8-24 Thd. 78 714-0131 Key 3/32" x 5/8" Dia.
27 712-0267 Hex Nut 5/16-18 Thd.* 80 725-1377 Plastic Key—Craftsman
28 712-0333 Nut V 2-20 Thd. 81 736-0105 Betl-Wash. .38" I.D. x .88"
29 712-0342 Hex Jam Nut 3/8-16 Thd. 82 736-0119 L-Wash. 5/16" I.D.'
30 717-0944 Transmission Comp. 86 747-0716 Belt Guard Scr.
31 732-0429 Extension Spring 3.97" Lg. 88 756-0538 Auxiliary PTO Pulley
; 32 736-0119 L-Wash. 5/16" I.D.' 89 784-5396 Engine Plate Ass’y.
( 33 736-0169 L-Wash. 3/8" I.D.* 90 713-0394 Chain #420 V 2 Pilch x 41 Links
34 736-0921 L-Wash. 1 / 2 " I.D.' 713-0723 #41 Master Link
35 738-0689 Shld. Bolt 1 / 2 " Dia. x .175" 91 715-0143 Spring Spiral Pin
36 750-0539 Spacer .315" I.D. 92 731-0973 Slide Washer
37 754-0356 V-Belt 93 738-0766 Free Wheeling Axle
38 756-0536 Flat Idler 1.88" Dia. 94 741-0490 Flange Brg. w/Flats .752 I.D.
39 756-0537 Trans. Pulley 7" O.D. x 3L 95 784-5393 30 T-Sprocket Hub Ass’y.
40 784-5314 Trans. Idler Arm 96 710-0603 Hex B-Tap Scr. 5/16-18 x .5"
41 784-5315 Trans. Support Plate Lg.
42 714-0129 Key 97 731-1042 Belt Cover
43 143.796132 Engine 98 723-0396 Tire Chains
44 710-0559 Hex Bolt 1/4-28 X 1.75" Lg. 99 726-0175 Clamp
45 736-0270 Bell-Wash. 1/4" I.D. 100 725-0157 Cable Tie
46 784-5390 Shift Arm
- ■ - ...............................................................................
‘Common Hardware—May be purchased locally.
“Early Production Uses;
710-0781 Hex Wash. Hd. B-Tap Scr.
3/8-16 X .875" Lg.
