REPAIR PARTS
ENGINE
TRACTOR - - MODEL NUMBER 917.258473
KEY
NO.
1
2
3
4
PART
NO.
132759
17720410
137352
13 272293
14 13280324
15 13200300
16 STD551237
23 156123
29 137180
31 109202X
32 123549X
33 123487X
35 17490512
37 137040
38
40 124028X
44 17490412
46 19091416
62 STD551131
72 71070512
78 17490620
81 128861
DESCRIPTION
Control Throt Rh Btk Pdl 15 10
Screw Hex Thd Cut 1/4-20x5/8 T
Engine {See Breakdown) B&S Model
28N707-0173-01
Muffler Exhaust B&S U
Gasket 1 313 Id Tin Plated
Nipple Pipe 3/8 NptX3"
Elbow Std 90 Degree 3/8-18 Npt
Washer Lock Ext Tooth 3/8
Shield Browning
Arrestor Spark
Tank Fuel 1 25 Fr
Cap Asm Fuel W/sym Vented
Clamp Hose BIk
Screw, Thdrol 5/16-18 x 3/4 Tyt
Line Fuel 20“
Plug Oil Drain (Order From Engine
Manufacturer)
Bushing Snap Nyl BIk Fuel Line
Screw Hexwsh Thdrol 1/4-20x3/4
Washer 9/32 X 7/8 X 16ga
Washer Lock Hvy Hid Spr 5/16
Screw Hexhd Cap 5/16-18x3/4
Screw Thdrol 3/8-16x1 -1 /4 Tytt
Nut Flange 1/4-20 Starter Nut
NOTE:
1 inch = 25.4 mm
43
