REPAIR PARTS
6 3 7 7 4 14 16 11
TRACTOR - - MODEL NUMBER 917.258473
KEY PART
NO. NO.
156834
160304
160305
150680
133644
151799
128314
10 149516
11 156439
12 4900J
13 146046
14 150678
1
3
4
5
6
7
9
DESCRIPTION
Decal, Insîaiction Opérât Eng
Decal, Hood Slope Rh Craftsman
Decal, Hood Slope Lh Craftsman
Decal, Grille Craftsman Sip LT Dov
Decal, Maint Customer Sears Dom
Decal, Panel Side
Decal, Fender Craftsman White
Decal, Clutch/brake Eng
Decal, V-belt Dr Sch Tractor
Decal, Chassis 42" 6sp
KEY PART
NO. NO. DESCRIPTION
15 160396 Decal, Mower Drive Schematic
16 140837 Decal, Saddle Brake Parking
17 150333 Decal, Cap Cnsmr Help Line Srs.
18 156787 Decal, Mower EZ3 Mulching Sears
21 131265 Decal, Lightbox
-- 138311 Decal, Lilt Handle
- - 145246 Pad, Footrest Rbr Sq Generic 95
- - 145247 Fastner Pop In Footrest
- -
161083 Manual, Owner’s (English)
-- 161084 Manual, Owner’s (Spanish)
WHEELS & TIRES
KEY PART
NO. NO. DESCRIPTION
Cap Value Tire
Stem Value
Tire F Ts 15 X 6 0 - 6 Sen/ice
Tube Inner Front #35060
Rim Asm 6"front White Service
Fitting Grease
Bearing Flange
Rim Asm 8"rear White Service
Tire R Ts 18x9 5-8 Service
Tube Rear 9 5X8 Service
Cap Axle Blk 1 50 X1 00
Sealant, Tire (10 oz. tube)
All component dimensions given in U.S. inches,
1 inch = 25.4 mm
1 59192
2 65139
3 106222X
4 59904
5 106732X427
6 278H
7 9040H
8 106108X427
9 106268X
10 7152J
11 104757X
.. 144334
NOTE:
41
