ACCESSORIES AND ATTACHMENTS
These accessories and altachments were available through most Sears retail outlets and service centers when the tractor was purchased,
Most Sears stores can order these items for you when you provide the mode! number of your tractor.
ENGINE MAINTENANCE
SPARK PLUG GAS CAN ENGINE OIL FUEL STABILIZER AIR FILTER
Á
/j=
A
t
PERFORMANCE
Sears offers a wide variety of attachments that fit your tractor Many of these are fisted below with brief explanations of how they can help
you. This list was current at the time of publication; however, it may change In future years - more attachments may be added, changes
may be made in these attachments, or some may no longer be available or fit your model. Contact your nearest Sears store for the
accessories and attachments that are avaifabie for your tractor.
Most of these attachments do not require additional hitches or conversion kits (those that do are indicated) and are designed for easy
attaching and detaching.
SLEEVE CULTIVATOR is 43 inches wide. Prepares ground for
seeding, helps weed control. Steel frame holds 5 adjustable sweeps.
Adjusts vertically, horizontally. (Requires sleeve hilch ) Optional
accessory: steel furrow opener for wider openings for potatoes,
com, and other deep-seeded crops.
SLEEVE HITCH for use with master lift system. Single pin couples/
uncouples.
SNOWTHROWER has 42-inoh swath. Drum-type auger handles
powdery and wet/heavy snow, Mounts easily with simple pin arrange­
ment. Discharge chute adjusts from tractor seat, 6-lnch diameter
spout discharges snow 10 to SO feet, Lift controHed at tractor seat,
(Use with chains and wheel weights and/or rear drawbar weight.)
SPRAYERS use 12-voit DC electric motorfhat connects to the tractor
battery or other 12-volt source Includes booms for automatic
spraying and hand held wand for spot spraying. Wand has adjustable
spray pattern. For applying herbicides, insecticides, fungicides and
liquid fertilizers.
SPREADER/SEEDERS make seeding, fertilizing, and weed killing
easy. Broadcast spreaders are also useful for granular de-icers and
sand.
SWEEPERS let you collect grass clippings and leaves
TILLER has 0 hp engine to prepare seed beds, cultivate, and compost
garden residue. Chain-drive transmission. Six 11-inch diameter one
piece heat-treated steel tines. Tills 30-inch path- (Requires sleeve
hitch.) Oruse 5 hp tow-behindTILLER with 36-inch swath to prepare
seed beds, cultivate and compost garden residue. Tiiler has its own
built-in lift and depth control system and does NOT require a sleeve
hitch. Fits any lawn, yard or garden tractor. Simply hook up to the
tractor drawbar and go! Optional accessories for 5 hp tiller convert
unit for dethatching, aerating, hilling...without toots,
TIRE CHAINS are heavy duly; closely spaced extra-large cross links
give srooolh ride, outstanding traction.
TRACTOR CAB has heavy duty vinyl fabric over tubular stee! frame,
ABS plastic top; dear plastic windshield offers 360 degree visibility.
Hinged metal doors with catch. Keeps operator warm and dry,
Remove vinyl sides and windshields for use as sun protecior in
summer. Optional accessories include: tlnled/tempered solid
safety glass windshield with hand operated wiper, 12-volt amber
caution light tor mounting on cab top,
VACS for powerful collection of heavy grass dippings and leaves.
Optional wand attachment to pick up debris in hard-to-reach places,
VAC/CHIPPER includes a chipper-shredder.
WEIGHT BRACKETfor drawbarfor snow removal applications. Can
be mounted on front of tractor for plowing applications. Uses (1) 55
lb weight.
WHEEL WEIGHTS for rear wheels provide needed traction for snow
removal or dozing heavy materials,
AERATOR promotes deep root growth for a healthy lawn. Tapered
2,5-inch steel spikes mounted on 10-inch diameter discs puncture
holes in soil at close intenrals to let moisture soak in Steel weight tray
for increased penetration,
BUMPER protects front end of tractor from damage,
CARTS make hauling easy. Variety of sizes avatiabie, plus accesso­
ries such as side panel kits, tooi caddy, cart cover, protective mat and
dolly.
CORING AERATOR takes small plugs out o! soil to allow moisture
and nutrients to reach grass roots 36-inch swath 24 hardened steel
coring tips. 1501b, capacity weight tray,
DISC HARROW has 2 gangs of 4 steel blades that angle from 10 to
20 degrees, 40 inches wide. Can hook 2 units in tandem. (Requires
sleeve hitch.)
DOZER BLADE removes snow; grades dirt, sand and gravel. 4B
inches wide, 17inchesh!gh,clears 44-inch path when angled. Master
lift control lever for operator ease Spring trip for snow removal on
uneven pavement; built-in float for blade to follow ground contour.
Reversible, replaceable scraper bar, (Use with lire chains and wheel
weights and/or rear drawbar weight .)
EASY OIL DRAIN VALVE makes oil changes easier, faster,
FRONT NOSE ROLLER canters in front of mower deck to reduce
chances of “scalping" on uneven terrain.
GANG HITCH lets you tow 2 or 3 pull-behtnd attachments at
once, such as sweepers, dethatchers, aerators (not for use with
rollers, carts or other heavy attachments).
MULCH RAKETOETHATCHER loosens sol! and flips thatch and
matted leaves to lawn surface tor easy pickup, Twenty spring tine
teeth. Useful to prepare bare areas for seeding. Available for front or
rear mounting. HIGH PERFORMANCE REEL-ACTION SPRING
TINE DETHATCHER covers 36-inoh wide path and tosses thatch into
large hopper. Mounts behind tractor.
PLOW turns soil 6 inches deep, cuts 10-lnoh furrow. Crank adjust­
ment controls depth, 3-positfon yoke sets width. Heavy steel (andside
for straight furrowfog. (Requires sleeve hitch,)
RAMP TOPS AND FEET let you load and unload tractor from a
pickup truck. Use with 2x8 or 2x10 lumber,
REAR GRADER BLADE is 42 Inches wide and operated from driver’s
seat. Reversible steel blade can be angled at 30 degrees for grading.
Reverses for pushing snow backwards. (Requires sleeve hitch,)
ROLLER for smootherlawn surface, 36-lnch wide, 18-inch diameter
water-tight drum holds up to 390 lbs, of weight. Rounded edges
prevent harm to turf. Adjustable scraper automatically cleans drum
