TRACTOR - - MODEL NUMBER 917.251551
SCHEMATIC
4-
-o
BATTERY
r
FUSE 30 AMP
-OXD-
1-----
_ _ ,
■
q
I
^ ;
STARTER
CLUTCH/BRAKE
(PEDAL UP)
SOLENOID
ELECTRIC CLUTCH
SEAT SWITCH
(NOT OCCUPIED)
PO
PTO
(DISENGAGED)
GROUNDING CONNECTOR
BLACK
I
-------------- 1
WHITE
-o
AFTER FIRE SOL_ENOID
I
IGNITION
UNIT
-O
SPARK
^ PLUGS
ENGINE
CONNECTIONS
NON-REMOVABLE
CONNECTIONS
REMOVABLE
CONNECTIONS
HEADLIGHT
SWITCH (OFF)
Q F C
HEADLIGHTS
/77
TRACTOR CONNECTOR
IGNITION SWITCH
"M" FOR ENGINE
SHORTING
(BLACK WIRE)
PTO SWITCH
POSITION
CIRCUIT
OFF
C + G
ON
C + F, B + E, A + D
OIL SENTRY
OPTION
(YELLOW WIRE
TO LIGHT PKG.)
BATTERY
CHARGING
(RED WIRE)
•SWITCHED
4-12V
(BLUE
WIRE)
ENGINE CONNECTOR
IGNITION SWITCH
POSITION
CIRCUIT
OFF
M Hh G
ON
B -f L
START
B + S -f L
WIRING INSULATED CUPS
NOTE: IF WIRING INSULATED
CLIPS WERE REMOVED FOR
SERVICING OF UNIT. THEY
SHOULD BE REPLACED TO
PROPERLY SECURE YOUR WIRING
REGULATOR'
(PURPLE WIRE.
RED WIRE)
CARBURETOR
SOLENOID
(RED WIRE,
BLUE WIRE)
ENGINE
SHORTING
(WHITE WIRE)
-OIL SENTRY
(GREEN WIRE)
