MAINTENANCE AND TROUBLE-SHOOTING

Most treadmill problems can be solved by following the simple steps below. If further assistance is
needed, call our toll-free HELPLINE at 1-800-736-6879, Monday through Saturday, 7 a.m. until 7 p.m.
Centra! Time (excluding holidays)^

PROBLEM: The power does not turn on

SOLUTION: a. Make sure that the power cord is plugged into a surge suppressor, and that the surge suppressor

is plugged into a properly grounded outlet (see page

). Use only a single-outlet surge suppressor

that is UL1449 listed as a transient voltage surge suppressor (TVSS). The surge suppressor

must have a UL suppressed voltage rating of 400 volts or less and a minimum surge dissipation

of 450 joules. The surge suppressor must be electrically rated for 120 volts AC and 15 amps.

b. After the power cord has been plugged in, make sure that the key is fully inserted into the con

sole. (See step 1 on page 9.)

c. Check the circuit breaker located on the treadmill

near the power cord. If the switch protrudes as

shown, the circuit breaker has tripped! To reset the
circuit breaker, wait for five minutes and then press
the switch back in.

d. Check the on/off switch located on the treadmill

near the power cord. The switch must be in the “on"
position.

• PROBLEM: The power turns off during use

SOLUTION: a. Check the circuit breaker located on the treadmill frame near the power cord (see 1. c. above). If

the circuit breaker has tripped, wait for five minutes and then press the switch back in.

b. Make sure that the power cord is plugged in.

c. Remove the key from the console. Reinsert the key fully into the console. (See step

on page 9.)

d. Make sure that the on/off switch is in the “on" position. (See 1. d. above.)

PROBLEM: The displays of the console do not function properly

SOLUTION: a. Remove the six screws from the hood. Carefully re

move the hood. Locate the Reed Switch (

) and the

Magnet (87) on the left side of the Pulley (85). Turn

the Pulley until the Magnet is aligned with the Reed
Switch. Make sure that the gap between the
Magnet and the Reed Switch is about 1/8”. If nec
essary, loosen the Screw-(35) and move the Reed
Switch slightly. Retighlen the Screw. Re-attach the
hood, and run the treadmill for a few minutes to check

for a correct speed reading.
