CONGRATULATIONS on your purchase of a Sears
tractor. It has been designed, engineered and manufac
tured to give you the best possible dependability and
performance..
Should you experience any problem you cannot easily
remedy, please contact your nearest Sears Service
Center/Department. We have competent, well-trained
technicians and the proper tools to service or repair this
tractor.
Please read and retain this manual. The instructions will
enable you to assemble and maintain your tractor prop
erly. Always observe the “SAFETY RULES".
PRODUCT SPECÎFICATÎONS
MODEL
NUMBER
SERIAL
NUMBER
917.255970
DATEOFPURCHASE
THE MODEL AND SERIAL NUMBERS WILL BE FOUND
ON A PLATE UNDER THE SEAT,
YOU SHOULD RECORD BOTH SERIAL NUMBER AND
DATE OF PURCHASE AND KEEP IN A SAFE PLACE
FOR FUTURE REFERENCE.
MAINTENANCE
AGREEMENT
A Sears maintenance agreement is available on this trac
tor. Contact your nearest Sears store for details.
CUSTOMER RESPONSIBILITIES
» Read and observe the safety rules.
® Follow a regular schedule in maintaining, caring for and
using your tractor.
• Follow the Instructions under “Customer Responsibili
ties" and "Storage” sections of this manual.
HORSEPOWER:
18.0
GASOLINE CAPACITY:
3 5 GALLONS
UNLEADED REGULAR
OIL (3.0 PINTS):
SAE 30 (above 32‘F)
SAE 5W-30 (below 32'F)
SPARK PLUG (GAP.025 IN„):
CHAMPION RJ-19LM
STD361458
VALVE CLEARANCE:
INTAKE ,004-,006 IN
EXHAUST ,007-.009 IN,
GROUND SPEED:
(MPH):
LO
HI
1st
.8
‘V
1,8
2nd
1.4
s*
3.4
3rd
2.4
/
5.5
Rev, „9 2,1
TRANSAXLE OIL
(4 QUARTS)
NON-DETERGENT
SAE 30 (ISO 100)
TIRE PRESSURE:
FRONT: 14PSI
REAR: 10PSI
CHARGING SYSTEM:
5 AMPS BATTERY
5 AMPS HEADLIGHTS
BLADE BOLT TORQUE:
30-35 FT, LBS,
WARNING:
This tractor is equipped with an internal
combustion engine and should not be used on or near any
unimproved forest-covered, brush-covered or grass-cov
ered land unless the engine's exhaust system is equipped
with a spark arrester meeting applicable local or state laws
(if any). If a spark arrester is used, it should be maintained
in effective working order by the operator.
In the state of California the above is required by law
Section 4442 of the California Public Resources Code).
Other states may have similar laws. Federàl laws apply on
federal lands. A spark arrester for the muffler is availa^ble
throui ■
■ “
..................... '
the
ugh your nearest Sears authorized service center (See
REPAIR PARTS section of this manual).
LIMITED TWO YEAR WARRANTY ON ELECTRIC START
RIDING
EQUIPMENT
For two (2) years from the date of purchase, if this riding equipment is maintained, lubricated and tuned up according to the
instructions in the owner’s manual, Sears will repair or replace, free of charge, any parts found to be defective in material or
workmanship.
This Warranty does not cover:
“ Expendable items which become worn during normal use, such as blades, spark plugs, air cleaners and belts..
•
Tire replacement or repair caused by punctures from outside objects, such as nails, thorns, stumps, or glass.
•
Repairs necessary because of operator abuse, negligence, improper storage or accident or the failure to maintain the
equipment according to the instructions contained in the owner’s manual.
•
Riding equipment used for commercial or rental purposes.
LIMITED 90 DAY WARRANTY ON BATTERY
For 90 days from date of purchase, if any battery inciuded with this riding equipment proves defective in material or workmanship
and our testing determines the battery will not hold a charge, Sears will replace the battery at no charge.
WARRANTY SERVICE IS AVAILABLE BY RETURNING THE RIDING EQUIPMENT TO THE NEAREST SEARS SERVICE
CENTER/DEPARTMENT IN THE UNITED STATES,
This Warranty gives you specific legal rights, and you may also have other rights which may vary from state to state,
SEARS, ROEBUCK AND CO., D/817 WA, HOFFMAN ESTATES, ILLINOIS 60179
