MAINTENANÜh
WHEN SERVICING USE ONLY IDENTICAL REPLACEMENT PARTS
POWER CORD OR SWITCH REPLACEMENT
1. UNPLUG YOUR SAW.
i^WARNING: FAILURE TO UNPLUG YOUR SAW
COULD RESULT IN ACCIDENTAL STARTING OR
SHOCK CAUSING SERIOUS INJURY OR DEATH.
2. Remove screws and wing nut securing handle
cover. See Figure 17.
3. Carefully lift handle cover away from tool.
4. Note the locations of all lead wiring inside the
handle and how each connection has been made.
IMPORTANT: When the new cord or switch is in­
stalled, identical connections must be made.
5. Remove the lead wires from the switch by insert­
ing a 1/32” diameter pin or nail into each switch
lead receptacle and pull the lead wires as shown
in Figure 16. This will release the wires. Remove
the pin or nail with a twisting motion.
6 . To replace lead wires, push each lead wire into its
proper receptacle. NOTE: Be sure to push lead
wires into switch as far as possible.
7. Locate the switch in the handle and place all wir­
ing so it cannot be pinched or contact screws
when handle cover is replaced.
8 . Replace handle cover, screws, and wing nut.
9. Tighten screws and wing nut securely.
1/32” DIAMETER
NAIL OR PIN
WING NUT
SCREW
Fig. 17
GENERAL
Only the parts shown on parts list, page 15, are in­
tended to be repaired or replaced by the customer.
All other parts represent an important part of the
double insulation system and should be serviced on­
ly by a qualified service technician.
Avoid using solvents when cleaning plastic parts.
Most plastics are susceptible to various types of
commercial solvents and may be damaged by their
use. Use clean cloths to remove dirt, carbon dust,
etc.
-
iLWARNING: DO NOT AT ANY TIME LET BRAKE
FLUIDS, GASOLINE, PETROLEUM-BASED PRO­
DUCTS, PENETRATING OILS, ETC. COME IN
CONTACT WITH PLASTIC PARTS. THEY CON­
TAIN
CHEMICALS THAT CAN DAMAGE,
WEAKEN, OR DESTROY PLASTICS.
When electric tools are used on fiberglass boat
sports cars, etc., it has been found that they are sul
ject to accelerated wear and possible prematui
failure, as the fiberglass chips and grindings ai
highly abrasive to bearings, brushes, commutate
etc. Consequently it is not recommended that th
tool be used for extended work on any fiberglas
material. During any use on fiberglass it is extreme!
important that the tool is cleaned frequently by blov
ing with an air jet. ALWAYS WEAR SAFET
GLASSES, DUST MASK, OR EYESHIELDS BEFOR
BEGINNING POWER TOOL OPERATION OR BLOV
ING DUST.
THE FOLLOWING RECOMMENDED ACCESSORIES WERE AVAILABLE AT THE TIME THIS MANUA
WAS PRINTED.
Cord Lock (9 2595)
Carrying Case (_^ 14702)
Rip Guide (^27679)
50’ 14 A.W.G. Ext. Cord (_^ 5821)
71/4 Saw Blade (9 32303) 7‘/4
71/4 Saw Blade (9 32423) 71 /,
71/4 Saw Blade (9 32494) 71/4
7 ‘/4 Saw Blade (9 32564) 7V a
100’ 14 A.W.G. Ext. Cord 83508) 7V a
Saw Blade (9 32664)
Saw Blade (9 32444)
Saw Blade (9 32526)
Saw Blade (9 32518)
Saw Blade (9 32489)
iàCAUTION: The use of attachments or accessories not listed above might be hazardous.
Page 12
