Sears 486.24412 - Manual (Page 15)

REPAIH PARTS LIST FOR MODEL 48"
dozer blade
REF.
NO.
PART NO, QTY. DESCRIPTION
REF.
NO.
PART NO, QTY. DESCRIPTION
1 62554 1 48" Blade Ass'y- 36 746-0260 2 Cable Fitting, End
2 R3132J 2 Shoe 37 43348 1 Angle Lock Spring
3 43079 8 Carriage Bolt 5/16-18 x 1"* 38 738-0234 1 Shoulder Bolt (Special)
4 43081 8 Washer 5/16 Std. Wrt.‘ 39 44072 1 Hex Whiziock Nut 3/8-16
5 43086 8 Lock Washer, Spring 5/16* 40 7071 1 Handle Grip 3/4"
6 43083 8 Hex Nut 5/16-18* 41 43343 10 Hairpin Cotter 1/8"*
7 23639 1 Wear Plate 48" 42 43064 1 Hex Lock Nut 5/16-18*
8 62556 1 Pivot Plate Ass'y. 43 41596 2 Hex Bolt 1/2-13 X 2"*
9 62944 1 Channel Ass'y. 44 712-0206 6 Hex Nut 1/2-13*
10 710-0741 1 Hex Bolt 3/4-10 X 3-1/2" 45 43510 2 Hex Bolt 1/2-13x2-3/4"*
11 1540-162 1 Washer 3/4" 46 43353 2 Lock Washer, Spring 1/2“*
12 40436 1 Hex Jam Nut 3/4-10* 47 710-0305 2 Carriage Bolt 3/8-16 x 1-1/4"*
13 736-0306 1 Washer 3/4 (Special) 48 43003 8 Lock Washer, Spring 3/8*
14 40598 1 Hex Lock Nut 3/4-10 49 43082 8 Hex Lock Nut 3/8-16*
15 9466R 2 Blade Adjustment Spring 50 1509-90 1 Hex Bolt 1/4-20 x 1-1/4"*
16 44071 2 Hex Bolt 3/8-16 X 3-1/2" 51 43866 1 Hex Bolt 1/4-20 x 5/8"*
17 43015 4 Hex Nut 3/8-16* 52 43013 3 Hex Lock Nut 1/4-20*
18 44074 2 Plastic Cap, 3/8" 53 23658 1 Spacer
19 62868 1 Guide Bracket Ass'y. 54 43085 1 Hex Bolt 5/16-18 X 1-1/2"*
20 23646 1 Blade Pivot Bracket 55 44044 4 Clevis Pin, 3/8" Dia. x 3/4" Lg.
21 62560 1 Tube Handle Ass'y. 66 43055 6 Hairpin Cotter 3/32"*
22 62561 1 Release Grip Ass'y. 57 43087 1 Hex Bolt 3/8-16x1-1/4“*
23 746-0366 1 Control Cable Ass'y 58 43070 1 Washer 3/8 Std. Wrt.*
24 62562 1 Handle Guide 59 23625 1 Pivot Bushing
25 23728 1 Support Bracket 60 43001 5 Hex Bolt 3/8-16 X r *
26 62951 1 Lift Ass'y. 61 712-0256 4 Hex Jam Nut 5/16-24*
27 45100 1 Hex Bolt 1/2-13 x 4"* 62 731-0869 1 Plastic Grip
28 23922 2 Lift Pivot Plate 63 43019 2 Hex Jam Nut 1/2-13*
29 23655 1 Stop Angle 64 43352 4 Washer 7/16 Std. Wrt.*
30 23624 2 Keeper Plate 65 23923 1 Frame Bracket (LH)
31 23151 2 Angle Lock Bar 66 23924 1 Frame Bracket (RH)
32 23631 1 Lift Arm Link 67 46001 2 Lift Rod Trunnion
33 43349 1 Spring Pin 1/4 X 1"* 68 43015 2 Hex Nut 3/8-16 Thread
34 05762 1 Cable Mount Bracket 69 43407 4 Hex Bolt 3/8-16 X 3/4" Long*
35 726-0178 1 Nylon Tie (Cable) -- 45185 1 Owners Manual |
Purchase common hardware locally.
Sears, Roebuck and Co. reserves the right to make
any changes in design or Improvements vi/ithout
imposing any obligation to install the same upon its
items heretofore manufactured.
