CRAFTSMAN 22" POWER-PROPELLED LAWN MOWER MODEL NUMBER 917.372301
REPAIR PARTS
w
CO
Ref.
No.
Part
No.
Part Name
Ref.
No.
Part
No.
Part Name
1 85759 Drive Control (IncL Ref. # 2,3) 29 74976 Retaining Ring
2 79875 Drive Hecid Kit
30 83691 V-Belf 3L
3 79980 Drive Control Cable Kit 31 54388 Hex Head Bolt i / 4 - ¿ Ú x 2 3/4
4 86261 Machine Screw 1/4-20 x 2 1/8 32 83632 Spring
S 53490 Locknut 1 /4-20 33 68038 Locknut 1/4-20
84886 Wheel & Tire Assembly 34 75192 Spring
7 52160 Washer 35 STD580009 Woodruff Key #213
8 55015 Retainer Clip 36 STD580014 Woodruff Key #3
9 77400 Hub Cap 37 83590 Drive Cover
10 77862 Selector Spring (R.F.) 38 69411
Pan Head Machine Screw l0-'24 x 1 3/4
11 77861 Selector Spring (t.F.) 39 75725
Pan Head Machine Screw 1Ü-24 x 2 3/4
12 77865 Selector Knob 40 79994 Wheel Adjuster Assembly (Left)
13 77858 ' Axle Arm Assembly
{IncL Ref. #11, 13, 14, 17, 18, 19)
14 86280 Wheel Adjuster Bracket 41 79995
Wheel Adjuster Assembly (Right)
15 86273 Spacer Bearing
(IncL Ref. # 10. 13, 14, 17, 18, 19)
16 86274 Spring Washer
42 84806 Catcher Frame
17 STD582087 Retaining Ring 43 85428 Catcher Top
18 61528 Flat Head Machine Screw 1 /4-20 x 3/4 44 84164 Catcher Bottom
19 63601 Locknut 1/4-20 45 83548 Catcher Baffle
20 76401 Dust Cover 46 83553 Clamp
21 74507 Pinion 47 12024 Truss Head Mochine Screw
22 STD581050 E-Ring
1/4-20
X
5/8
23 81612 Lockwasher 48 83555 Truss Head Machine Screw
24 81220 Shoulder Nut
10-24 X 5/8
25 STD601003 Self-Tapping Screw 10-24 x 3/8 49 69180 Locknut 10-24
26 83700 Cable Clamp
50 53838 Keps Nut 1/4-20
27 79949 Gear Case Replacement Kit 51 85878 Clipping Deflector Accessory
28 83681 Drive Pulley
{Not Included w/Mower)
\
