CRAFTSMAN 22” POWER-PROPEUED LAWN MOWER MODEl NUMBER 917.372301
REPAIR PARTS
CO
Ref.
No.
Pori
No.
Part Name j
Ref.
No.
Part
No.
Part Name
1 85755 Upper Handle 20 62363 Spring-Lever
2 84683 Lower Handle 21 77524 Rear Door
3 85523 Zone Control 22 81027 Hinge Bracket
4 86261 Machine Screw 1/4-20 x 2 1/8 23 77526 Hinge Rod
5 53490 Locknut 1/4-20 24 77527 Spring
6 85548 Control Bar 25 STDS81025 E-Ring
7 STD523117 Handle Bolt 26 STD512505 Hex Head Tapping Screw 1 /4-20 x 1 /2
8 63688 Handle Knob 27 83935 Door Seal
9 85424 Trim Plate 28 79997 Housing Assembly (Incl. Ref. #26, 29,
10 85529 Nylon Bushing
30, 31, 32, 33, 34, 35, 64}
11 85825 Self-Tapping Screw 10-24 x 1 29 85463 Danger Decal
12 STD551025 Washer 30 85375 Back Plate
13 85436 Hex Wosher Head Machine Screw 31 85877 Back Plate Bracket
1/4-20 X 1 1/2 32 STD512505 Hex Head Machine Screw 1 /4-20 x 1 /2
14 53490 Locknut 1 /4-20 33 63601 Locknut 1 /4-20
15 34372A Bracket Rope Guide (See Engine Parts 34 77514 Side Baffle
List)(Source 143) 35 81283 Hex Self-Tapping Screw 10-24 x 3/8
16 85827 Control Coble Clip 36 77521 Rear Skirt
17 51793 Hairpin Cotter 37 85546 Backing Strip
18 81281 Hondle Lever 38 85354 Dischorge Baffle
19 85535 Handle Knob 39 57917 Hex Head Machine Screw 1 /4-20 x 3/4
40 63601 Locknut 1/4-20
