Solar Collector Panel Thermistor ~ The collector
thermistor should be placed on the leaving tube on
an interior panel in the panel array. One of the
interior panels should be used because of reduced
edge losses and higher performance. The thermistor
should be butted up against the panel and secured
in place on the tube with a hose clamp, as
illustrated in Fig. 15. Do not overtighten clamp.
Insulate sensor and tubing.
Thermistor Wiring — (See Electrical Data and
Wiring, pg 20.)
15
