A-3
Compaq SW3322/SW3323/SW3324 Dual-Speed Switch User Guide
Writer: Fran Spragens Project: Technical Specifications Comments:
File Name:3324_a99.doc Last Saved On:3/15/99 2:40 PM
Memory
§
Processor DRAM: 2 MB (SW3322/3323), 4 MB (SW3324)
§
Packet Buffer Memory: 4 MB/8 ports of 10/100Mb/s, 8MB/Gigabit
Ethernet ports
§
Flash Memory: 1 MB (SW3322/SW3323), 2 MB (SW3324)
Port Specifications
Console Port
Table A-1 shows the console port pin assignments.
Table A-1
RS-232 Console Port Pin Assignments
Pin Signal Name
1 RTS/CTS
2 TXD
3 RXD
4 DSR
5 GND
6 DTR
7 DCD
8 DCD
9 Not Used
