3-22 User Interface
Writer: Fran Spragens Project: User Interface Comments:
File Name:3324_3.doc Last Saved On:3/16/99 3:05 PM
Table 3-16 describes the the Port Menu
Table 3-16
Port Menu Descriptions
Field Description
ID The port identification number.
Port Name The administrative name assigned to the port (1-14 character range).
Enabled The current “enabled” state of the port, either “Yes” or “No.”
Link Status The current link state of the port, either “connected” or “disconnected.”
Auto Negotiated The current state of auto-negotiation, whether or not auto-negotiation is complete,
“Yes” or “No”
Full Duplex The current full duplex state of the port, either “Yes” or “No.”
Speed The current speed of the port, either 10Mbps or 100Mbps.
Flow Control The current enable/disable state of flow control on the port, either “Yes” or “No.”
Next Page, Previous
Page, First Page,
Last Page
Display the selected page of the table.
Refresh Refreshes the screen to reflect latest system conditions.
Configure Enter a port number and to open the Port Configuration Menu to configure a specific port.
