3-9
Compaq SW3322/SW3323/SW3324 Dual-Speed Switch User Guide
Writer: Fran Spragens Project: User Interface Comments:
File Name:3324_3.doc Last Saved On:3/16/99 3:05 PM
Table 3-5 describes the Switch Configuration Menu.
Table 3-5
Switch Configuration Menu Descriptions
Selection Description
Forwarding Table Configuration Menu Menu for configuring the switch forwarding table.
Spanning Tree Configuration Menu Menus for configuring the switch Spanning Tree operation.
VLAN Configuration Menu Menu for configuring the VLAN operation of the switch.
Forwarding Table Aging Time Time in seconds until entries in the filter table are aged out if
not accessed (10-1,000,000 second range).
Broadcast Cutoff Rate Per second rate past which broadcast and destination unknown
frames are not flooded through the switch to help alleviate
broadcast storms (100-500,000 frames per second range). A
value of 0 disables this function.
Port Mirroring Enable Allows you to enable (Yes) or disable (No) port mirroring.
Mirrored Port The source port for the data to be mirrored.
Mirroring Port The destination port for the data to be mirrored.
Class of Service Configuration Menu Menu for configuring Class of Service for the switch.
Transmit Data Mirroring Enable Allows enable/disable port transmit data mirroring
Receive Data Mirror Enable Allows enable/disable port receive data mirroring
