3-25
Compaq SW3322/SW3323/SW3324 Dual-Speed Switch User Guide
Writer: Fran Spragens Project: User Interface Comments:
File Name:3324_3.doc Last Saved On:3/16/99 3:05 PM
Table 3-18 describes the Switch Statistics Screen
Table 3-18
Switch Statistics Screen Descriptions
Field Description
ID The port identification number.
Transmitted Number of frames transmitted out the port.
Received Number of frames received on the port.
Forwarded Number of frames forwarded through the port.
Filtered Number of frames filtered on the port.
Dropped Number of frames received that were dropped by the switch due to lack of resources.
Errored Number of errored frames received on the port.
Next Page, Previous
Page, First Page,
Last Page
Display the selected page of the table.
Switch Summary Allows you to open the Switch Summary Screen.
Port Statistics Allows you to open the Port Statistics Screen.
Refresh Refreshes switch statistics.
Clear Clears (or sets to zero) switch statistics.
