Page 85
B-5
Connectors, Adapters and Cable Connections
Adapters
H8571-J Adapter
Figure B-3 shows the H8571-J adapter (6-pin MMJ connector to 9-pin D-Sub
connector) and its pin assignments.
Figure B-3. H8571-J Adapter
H8575-A Adapter
Figure B-4 shows the H8575-A adapter (6-pin MMJ connector to
25-pin D-Sub connector) and its pin assignments.
Figure B-4. H8575-A Adapter
