Configuring the Router
4-13
[3] Show Current Settings
This option shows the router’s current settings. If the router is being
configured for the first time, some of the fields will be blank.
The following example shows the screen display associated with this
selection.
Enter selection : 3
SmrtSwtch Rtr 5xx
... Press Return to continue ...
SmrtSwtch Rtr 5xx,Brouter:1 Enet 1T1 1BRI,HW=1,RO=1,#4105,SW=v3.0-3
SysUpTime : 00:07:22 23 resets
SNMP Read/Write Community : Not Available
Default Gateway : Not Configured
Interface IP Address Subnet Mask Other Info
Ethernet 134.1.147.150 255.255.255.0
===============================================================
===============================================================
Press Return for Main Menu ...
===============================================================
===============================================================
SmrtSwtch Rtr 5xx
