OPERATING INSTRUCTIONS cont'd.
SIDE PANEL - REMOVAL / REPLACEMENT
(For Care Cliner Models ONLY)
1. For ease of cleaning and chair maintenance;
Unscrew two (2) thumbscrews at the front
of chair and one (1) thumbscrew at the rear of
chair, on inside of each panel. (FIG. 1)
2. Replace panel and re-install three (3) thumb-
screws & clear washers (FIG.2) when
cleaning or maintenance of chair is complete.
FIG. 1
DROP-ARM VINYL PANEL
(For Drop-Arm Care Cliner Models ONLY)
1. The vinyl panel is secured to the bottom of the Drop-
Arm with a hook & loop fastener material. Peel hook
& loop apart to allow ease of cleaning and access
behind the Drop-Arm of the chair.
(FIG. 3 & 4)
2. Re-attach by aligning and firmly pressing the hook &
loop material back together.
FIG. 2
FIG. 3
7
FIG. 4
SWING-ARM OPERATION
(Models 6940 / 6950 only)
