24 | PIR Ready VT7200 Series-Installation Guide

Pband
Proportional band setting
Default is : 3

Adjust the proportional band used by the Terminal Equipment

Controller PI control loop.

Note that the default value of 3.0 °F (1.2 °C) gives

satisfactory operation in most normal installation cases. The
use of a proportional band different than the factory one is
normally warranted in applications where the Terminal
Equipment Controller location is problematic and leads to
unwanted cycling of the unit. A typical example is a wall
mounted unit where the Terminal Equipment Controller is
installed between the return and supply air feeds and is
directly influenced by the supply air stream of the unit.


VALUE

°

F SCALE PBAND

°

C SCALE

PBAND

3

3 F

1.2 C

4

4 F

1.7 C

5

5 F

2.2 C

6

6 F

2.8 C

7

7 F

3.3 C

8

8 F

3.9 C

9

9 F

5.0 C

10

10 F

5.6 C
