13
G) Schedule set (4 events)
Schedule
set Y/N
This section of the menu permits the user to set the whether 2 or 4 events is needed. Each day can be tailored to specific schedules if
needed.
• 4 events can be programmed per day.
• Occupied & Unoccupied periods can be set for each day.
• Programming the 3 rd. & 4 th. events to the same time will cancel the last period.
Monday timer
Schedule set
Tuesday timer
Schedule set
Wednesday timer
Schedule set
Other days are identical
Monday
set? Y/N
No next →
Yes down ↓
Tuesday
set? Y/N
No next →
Yes down ↓
Wednesda
set? Y/N
No next →
Yes down ↓
Selects the day to be programmed or
modified
Yes key to access day scheduling, No key to jump to next day
Occupied
Day? Y/N
No next →
Yes down ↓
Occupied
Day? Y/N
No next →
Yes down ↓
Occupied
Day? Y/N
No next →
Yes down ↓
Yes = Daily schedules will be accessed
No = Unoccupied mode all day
Yes key to access day scheduling, No key to jump to next day
Copy Y/N
Previous
Yes next →
No down ↓
Copy Y/N
Previous
Yes next →
No down ↓
Yes = Will copy previous day schedule
No = Daily schedules will be accessed
Yes key to copy previous day, No key to set new time value for each day
Occupied
00:00 AM
Use ▲▼
To set value
Occupied
00:00 AM
Use ▲▼
To set value
Occupied
00:00 AM
Use ▲▼
To set value Sets Event # 1 Occupied time
Will activate occupied setpoints
Use ▲▼ to set value, Yes key to confirm
Unoccup
00:00 AM
Use ▲▼
To set value
Unoccup
00:00 AM
Use ▲▼
To set value
Unoccup
00:00 AM
Use ▲▼
To set value Sets Event # 2 Unoccupied time
Will activate unoccupied setpoints
Use ▲▼ to set value, Yes key to confirm
Occupie2
00:00 AM
Use ▲▼
To set value
Occupie2
00:00 AM
Use ▲▼
To set value
Occupie2
00:00 AM
Use ▲▼
To set value Sets Event # 3 Occupied time
Will activate occupied setpoints
Use ▲▼ to set value, Yes key to confirm
Unoccup2
00:00 AM
Use ▲▼
To set value
Unoccup2
00:00 AM
Use ▲▼
To set value
Unoccup2
00:00 AM
Use ▲▼
To set value Sets Event # 4 Unoccupied time
Will activate unoccupied setpoints
Use ▲▼ to set value, Yes key to confirm
Ex. #1 Four event retail establishment schedule
Event Period 1 - Event 1 Period 1 - Event 2 Period 2 - Event 3 Period 2 - Event 4
Setpoint Occupied Unoccupied Occupied Unoccupied
Cool Heat Cool Heat Cool Heat Cool Heat Daily
72 °F 70 °F 80 °F 62 °F 72 °F 70 °F 80 °F 62 °F Occupancy
Monday 7.00 AM 5.00 PM 12.00 PM * 12.00 PM * Day time only
Tuesday 7.00 AM 5.00 PM 12.00 PM * 12.00 PM * Day time only
Wednesday 7.00 AM 5.00 PM 12.00 PM * 12.00 PM * Day time only
Thursday 7.00 AM 5.00 PM 7.00 PM 10.30 PM Day/evening time only
Friday 7.00 AM 5.00 PM 7.00 PM 10.30 PM Day/evening time only
Saturday 12.00 PM * 12.00 PM * 12.00 PM * 12.00 PM * Unoccupied
Sunday 12.00 PM * 12.00 PM * 12.00 PM * 12.00 PM * Unoccupied
* Programming events to the same time will cancel the last period and leave the thermostat in unoccupied mode
Ex. #2 Residential
Event Period 1 - Event 1 Period 1 - Event 2 Period 2 - Event 3 Period 2 - Event 4
Setpoint Occupied Unoccupied Occupied Unoccupied
Cool Heat Cool Heat Cool Heat Cool Heat Daily
72 °F 70 °F 80 °F 62 °F 72 °F 70 °F 80 °F 62 °F Occupancy
Monday 6:00 AM 8:00 AM 4:00 PM 10:00 PM Day/evening time only
Tuesday 6:00 AM 8:00 AM 4:00 PM 10:00 PM Day/evening time only
Wednesday 6:00 AM 8:00 AM 4:00 PM 10:00 PM Day/evening time only
Thursday 6:00 AM 8:00 AM 4:00 PM 10:00 PM Day/evening time only
Friday 6:00 AM 8:00 AM 4:00 PM 11:30 PM Day/evening time only
Saturday 8:00 AM * 8:00 AM * 8:00 AM * 11:59 PM * Day time only
Sunday 12:00 AM * 12:00 AM * 12:00 AM * 11:59 PM * Occupied all day
* Programming consecutive events to the same time will cause the thermostat to choose the last event as the time at which it will set its
schedule. In the above example for Saturday, the thermostat will control to the occupied set point from 8:00 AM until 11:59 PM.
Since it is desired to be in occupied mode throughout the night, then it is necessary to program the first event on Sunday at 12:00
AM. The thermostat will force a one minute unoccupied period for a one minute period (between 11:59 PM and 12:00 AM on
Saturday)
