VC3000 Series 8 Installation Guide
Viconics Technologies Inc. I Small Building Systems I 9245 Langelier Blvd. Saint-Leonard, Quebec, Canada, H1P 3K9 I +1 514 321 5660 I www.viconics.com
028-0296-07 May 2013 bm
© 2
01
3 V
ic
on
ic
s T
ec
hn
ol
og
ie
s. A
ll r
ig
ht
s r
es
er
ve
d
.
VC3000 series transformer relay packs are to be used only as
operating controls. If installed incorrectly the intended application may
fail or lead to personal injury or loss of property. It is the responsibility
of the end user to ensure that the device has been properly installed
and that proper safety precautions have been taken to protect against
possible failures. Tampering with the devices or incorrect application
of the device will void the warranty.
100 mm (3.94”)
80 mm (3.15”)
122 mm (4.80”) 80 mm (3.15”)
70 mm (2.75”)
33 mm (1.30”)
IMPoRtant notICe
DIMensIons
