24
C
Place the ink cartridge shown in the diagram below.
CAUTION
Do not touch the electrical contact on the carriage. Doing so may cause
a malfunction.
NOTE
Do not use more than one cartridge by rotation. If you do so, applications
cannot check the ink level precisely.
D
Push down the ink cartridge until it clicks into place.
IMPORTANT
Make sure that the ink cartridge is securely in place.
E
Squeeze the Print Position Adjustment Lever and move it to
adjust the print position.
F
Carefully replace the Top Cover.
Top:
1.92" (48.8 mm) from the
bottom edge of the
document
Bottom:
1.17" (29.6 mm) from the
bottom edge of the
document
