Cooling water minimization
Cooling water valve 24 V= ...................................... 67 60 13
-
compact design, designed for a high number of operations
at short intervals
- solenoid systems with splash protection
- conductance optimised for applications with rotary evapora-
tor and exhaust waste vapour condenser
- with integrated Y-connector to connect an isolation valve
Cooling water valve 230 V~, 50-60 Hz ..................... 67 60 10
(for use with the VMS)
Y-socket-plug connector ......................................... 67 60 15
(to connect several components to the bush of the CVC 2
II , e. g.
for simultaneous operation of isolation valve and VMS)
Accessories of controller
Solenoid operated isolation valve
VV 6C 24 V= ............................................................. 67 40 91
(PVDF/PTFE, small flange NW 16, hose nozzle NW 6/10)
Solenoid operated isolation valve
VV 6 24 V= ............................................................... 67 40 90
(PP/FPM, small flange NW 16, hose nozzle NW 6/10)
Solenoid operated isolation valve
VV 15C 24 V= ........................................................... 67 41 10
(PVDF/PTFE, small flange NW 16)
Solenoid operated isolation valve
VV 15 24 V= .............................................................. 67 41 15
(PVDF/PTFE, small flange NW 25)
Vacuum distribution
VACUU•LAN ® manual flow control module
VCL 01 ...................................................................... 67 71 06
VACUU•LAN
® shut off / manual flow control
module VCL 02 ........................................................ 67 71 07
VACUU•LAN
® automatic control module
VCL 10 ...................................................................... 67 71 08
VACUU•LAN
® manual flow control/automatic control
module VCL 11 ........................................................ 67 71 09
The VACUU•LAN ® modules allow process orientated, flexible
and cost effective connections according to the requirements:
One vacuum pump for multiple work stations.
On this page we offer only a small selection of VACUU•LAN ® options. Please refer for further information.
VCL 01
VCL 10
VCL 02
VCL 11
