Page 40

page 40 of 92
➨
Air and pumped media might react inside the pump or
at the outlet of the pump and form hazardous or explo-
sive mixtures, when you use air rather than inert gas
for the gas ballast. This constitutes a risk of significant
damage to equipment and/or facilities, a risk of per-
sonal injury or even loss of life.
+
Make sure that air/gas intake through the gas ballast
valve can never lead to hazardous, explosive or other-
wise dangerous mixtures. If in doubt, use inert gas.
To reduce condensation in the pump, do not pump vapor
before the pump has reached its operating temperature.
Open the gas ballast valve when pumping condensable
vapors. Turn gas ballast cap to open valve.
NOTICE
gas ballast
(open)
For
condensable vapors (water vapor, sol-
vents, etc.):
- The gas ballast valve is open if the arrow on
the gas ballast cap is pointing towards the
inlet of the pump.
- With gas ballast valve open, the ultimate
vacuum will be reduced.
- Use inert gas for gas ballast to avoid the formation of
explosive mixtures. A special adapter fitting is needed
to connect an inert gas supply line (see “Accessories
/ Spare parts”, pg. 43). This adapter replaces the
standard gas ballast cap and allows for an inert gas
line to be connected via a KF DN 16 small flange at a
maximum supply pressure of 17.5 psi (1.2 bar) abso-
lute.
- Close the gas ballast valve by turning the cap 180°.
In case of low boiling solvents (when the formation of
condensate is unlikely), the use of gas ballast might be
unnecessary. Operating the pump without gas ballast in-
creases the solvent recovery rate at the exhaust waste
vapor condenser.
