General technical data valid for all pumps
Coolant connection
(waste vapor condenser, only ”EK”)
hose nozzle for tubing
I.D. 1/4” - 5/16”
(hose nozzle DN 6-8 mm)
Maximum permissible pressure of
coolant at waste vapor condenser (”EK”)
psi
(bar)
87 (absolute)
(6 (absolute))
Permissible range of coolant tempera-
ture (waste vapor condenser, only ”EK”)
°F
(°C)
5 to 68
(-15 to +20)
Volume of catchpot (only ”AK” / ”EK”)
quarts
(ml)
0.52
(500)
Dimensions L x W x H approx.
+ EK
+ AK + EK
in
(mm)
in
(mm)
in
(mm)
21.0 x 10.2 x 14.1
(533 x 260 x 359)
20.8 x 15.2 x 15.6
(528 x 387 x 395)
24.3 x 15.2 x 15.6
(616 x 387 x 395)
Weight approx.
+ EK
+ AK + EK
lbs. (kg)
lbs. (kg)
lbs. (kg)
61.9 (28.1)
64.2 (29.1)
65.5 (29.7)
Type
ME 16C NT
ME 16C NT + EK
Maximum pumping speed 50/60 Hz*
(ISO 21360)
cfm
(m
3
/h)
9.6 / 10.8
(16.3 / 18.4)
Ultimate vacuum (absolute)
without gas ballast
Torr
(mbar)
53
(70)
Ultimate vacuum (absolute)
with gas ballast
Torr
(mbar)
75
(100)
A-weighted emission sound pressure
level** (uncertainty K
pA
: 3 dB(A))
dB(A)
54
