PCA I NSTRUCTION M ANUAL
Ultra Stereo Labs, Inc.
- 11 -
PCA Export
It is recommended but not required that you stop the scanning before exporting
any data.The PCA export function is designed to allow a recording of PCA
data displayed into either Microsoft Word or Microsoft Excel compatible
documents. At this time, only the MS Word export will contain a specified
company logo and the actual spectral readout of the current scanned sample.
The MS Excel compatible file will only contain the Luminance CIE x, CIE y
and Color Temperature readings.
To export, click the “Export” button on the PCA main screen. When the “Export”
dialog is displayed (Figure 6), select the type of document you wish to export
to. Then, you must specify a filename in the “Export To” section by clicking the
“Browse....” button and specifying a valid filename. If you are exporting to a
Microsoft Word document, you can also specify a company logo that will
appear in the header of the exported document by clicking the “Logo....” button
and selecting a valid image file.
An email feature is also included so that the PCA software can attach your
exported document to an email. To do this, simply check the “Send to e-mail
recipient” checkbox. When you have specified the documents type, filename,
logo and email option, click the “Export” button to export the scan data. You
may be prompted with additional screens if you elected to email the document.
SPECIFICATIONS
Viewfinder angle of view:
Angle of sensitive area:
Luminance range:
Luminance accuracy:
Chromaticity accuracy:
Figure 6
