Selecting a pressure transducer with the appropriate

range is critical in order to get accurate measurements

using the piezometer ring. Since most transducers list

accuracy as a percent of full scale, if the range selected

is too high, this can have a significant impact on the

accuracy of the flow measurement. If the range is too

low, there is risk of damaging the instrument and/or get-

ting inaccurate readings or no reading at all.

The following steps are for sizing the pressure trans-

ducer for use with the piezometer ring flow measurement

system:

1. Determine the maximum flow rate in CFM that the

fan is expected to produce. This maximum should be

the greater of normal, maximum, and/or emergency

conditions.

2. Find the formula for calculating the actual flow rate

from page 1 of this document for the corresponding

size and type of fan being used.

3. Calculate the pressure drop corresponding to the

maximum flow rate determined in Step 1.

4. Select the pressure transducer with the smallest

range that includes the pressure drop calculated in

Step 3.

5. Now take the maximum range from the pressure

transducer selected in Step 4 and use that to calcu-

late the maximum flow rate that could be measured

with this transducer.

6. Determine an acceptable safety factor for sizing the

transducer.

7. Multiply the maximum flow rate from Step 1 by the

safety factor. If the maximum flow rate from Step 5

is less than the result, bump up the transducer to

the next largest size. Otherwise, the transducer from

Step 4 should be used.

Example:

Company XYZ has a size 270 BC SWSI fan to be

installed with design conditions of 12,000 CFM at 5

inches w.g. and standard density. What size transducer

should be used?

1. After speaking to the design engineer, it was deter-

mined that 12,000 CFM is the actual maximum and

most of the time the fan will be running closer to

10,000 CFM. Therefore, 12,000 CFM will be used for

the calculations.

2. The calculation for this fan type and size is:

ACFM = 4247.77 * (

∆P) for standard density

Note that if the density was other than standard air,

the formula would be different.

3. By rearranging the formula in Step 2, the following

formula is obtained:

∆P = (ACFM/4247.77)^2

so,

∆P = (12000/4247.77)^2 = 7.98 inches w.g.

4. For the pressure transducer models being considered,

the ranges are 0-3, 0-6, 0-10, and 0-20. Therefore,

for this flow rate the transducer model is the 0-10

inches w.g. model.

5. The maximum for this transducer is 10 inches, which

corresponds to the following flow rate:

ACFM = 4247.77 * (10) = 13433 CFM

6. Since 12,000 CFM is the maximum and normal oper-

ating conditions are 10,000 CFM, a 10% safety factor

should be plenty for this application

7. From step 1, 12000 CFM * 1.1 = 13200 CFM. This

is less than 13433 CFM, so the 0-10 inch pressure

transducer is acceptable.

Transducer Sizing for Piezometer Ring
