19
Product Specifications
3”
7
1/
2”
Wall Surface
1/2” NPSC
IDWH Sensor
Connection
3/4” NPSC
Boiler Return
1 1/2”
10
”
6 1
/4”
4 1
/4”
Wall Surface
1/2” NPT
Domestic hot
3/4” NPSC
Boiler Supply
1/2” NPT
Domestic Cold
Typ
1/
4”
1/
4”
2
”
9 1/4” OD
18
”
Boiler Supply
Domestic
Boiler Return
Front View
Bottom View
Top View
NOTE:
1. Domestic capacity is based on an intermittent draw with 50ºF inlet temperature and 120ºF outlet tempera-
ture.
